APC Smart-UPS RC 2000VA 230V SRC2KI

~~$ 840.00~~ $ 828.00

Part Number: SRC2KI
Max Configurable Power (Watts) 1.6kWatts / 2.0kVA
Output Voltage Note Configurable for 220 : 230 or 240 nominal output voltage
Input frequency 50/60 Hz
Input voltage range for main operations 100 - 280 Adjustable, 160 - 280V
Other Input Voltages 220, 240
Standard warranty 2 years repair or replace.

Order Now

Specification

Part Number: SRC2KI
Overview
Presentation: High density, double-conversion on-line power protection with scalable runtime.
Lead time: Usually in Stock
Main
Main Input Voltage: 230 V
Product or component type: Uninterruptible power supply (UPS)
Other Input Voltage: 220 V, 240 V
Main Output Voltage: 230 V
Other Output Voltage: 220 V, 240 V
Rated power in W: 1600 W
Rated power in VA: 2000 VA
Input Connection Type: IEC 60320 C14
output connection type: 4 IEC 60320 C13
Cable length: 1.2 m
Number of cables: 1
Provided equipment: Basic UPS signalling RS-232 cable, CD with software, User manual, USB cable
Range of product: Smart-UPS On-Line
Batteries & Runtime
Efficiency: View Efficiency Graph
Battery type: Lead-acid battery
Battery voltage: 48 V
Extended runtime: 0
Number of battery filled slots: 1
Number of battery free slots: 0
Battery recharge time: 3 h
Battery life: 3…5 year(s)
Battery charger power: 144 W rated
General
Number of power module filled slots: 0
Number of power module free slots: 0
Redundant: No
UPS type: Double conversion online
Physical
Colour: Charcoal
Height: 26 cm
Width: 14.5 cm
Depth: 39.7 cm
Net weight: 18 kg
Mounting preference: No preference
Mounting mode: Not rack-mountable
Two post mountable: 0
USB compatible: Yes
Mounting position: Vertical
Input
Load power factor: 0.8
Input voltage limits: 160...280 V
Network frequency: 50/60 Hz
Output
Bypass type: Built-in bypass
Crest factor: 3 : 1
Harmonic distortion: Less than 3 %
Maximum configurable power in VA: 2000 VA
Maximum configurable power in W: 1600 W
Output harmonic distortion: < 3% linear load
Wave type: Sine wave
Output frequency
- 50/60 Hz +/- 3 Hz sync to mains
- 50/60 Hz +/- 1 Hz unsynchronised
Additional information: Configurable for 220 : 230 or 240 nominal output voltage
Conformance
Standards
- EN/IEC 62040-1:2019/A11:2021
- EN/IEC 62040-2:2006/AC:2006
- EN/IEC 62040-2:2018
Environmental
Acoustic level: 50 dBA
Ambient air temperature for operation: 0…40 °C
Ambient air temperature for storage: -20…50 °C
Relative humidity: 0…95 %
Storage Relative Humidity: 0…95 %
Communications & Management
Emergency power off: Yes
Free slots: 1
Alarm: Alarm when on battery : distinctive low battery alarm : overload continuous tone alarm
Surge Protection and Filtering
Data line protection: RJ45 modem/fax protection (four wire dual line)
Surge energy rate: 600 J
Noise suppression: Full time multi-pole noise filtering : 0.3% IEEE surge let-through : zero clamping response time : meets UL 1449
Packing Units
Unit Type of Package 1: PCE
Number of Units in Package 1: 1
Package 1 Height: 23 cm
Package 1 Width: 59 cm
Package 1 Length: 32.5 cm
Package 1 Weight: 19.8 kg
Warranty 2 years repair or replace.
