Dahua NVR5216-4KS2 16Ch 1U 2HDDs 4K NVR

~~$ 240.00~~ $ 230.00

Part Number: NVR5216-4KS2
16-ch IP video access
Smart H.265+/Smart H.264+/H.265/H.264/MJPEG; H.265 auto switch
Max. decoding capability: 16 × 1080p@30 fps. Supports adaptive decoding
Max 320 Mbps incoming bandwidth
Up to 24MP resolution for live view and playback
1-channel fisheye dewarping (AI by NVR)
AI by Camera: Perimeter protection; face detection and recognition; SMD Plus; video metadata; ANPR; people counting; stereo analysis; crowd distribution; heat map
NVR5832-R-4KS2/NVR5864-R-4KS2 support RAID function
Warranty: 1-year on part.

Order Now

Specification

Part Number: NVR5216-4KS2
Technical Specification
System Main Processor: Quad-core embedded processor
Operating System: Embedded LINUX
Audio and Video
IP Camera: Input 16 Channel
Two-way Talk: 1 Channel Input, 1 Channel Output, RCA
Display
Interface: 1 HDMI, 1 VGA
Resolution HDMI: 3840 × 2160 , 1920 × 1080 , 1280 × 1024, 1280 × 720 , 1024 × 768 VGA: 1920 × 1080 , 1280 × 1024, 1280 × 720 , 1024 × 768
Decoding Capability: 4-ch@8MP(30fps), 16-ch@1080P(30fps)
Multi-screen Display 16CH: 1/4/8/9
OSD: Camera title, Time, Camera lock, Motion detection, Recording
Recording
Compression: Smart H.265+/H.265/Smart H.264+/H.264/MJPEG
Resolution: 12MP with 15fps, 8MP, 6MP, 5MP, 4MP, 3MP, 1080P, 1.3MP, 720P, D1, CIF with 30fps
Bit Rate: 16Kbps ~ 20Mbps Per Channel Record Mode Manual, Schedule (Regular, MD(Motion Detection) , Alarm, IVS), Stop
Record Interval: 1 ~ 120 min (default: 60 min), Pre-record: 1 ~ 30 sec, Post-record: 10 ~ 300 sec
Video Detection and Alarm
Trigger Events: Recording, PTZ, Tour, Alarm Out, Video Push, Email, Snapshot, Buzzer and Screen Tips
Video Detection: Motion Detection, MD Zones: 396 (22 × 18), Video Loss and Tampering
Alarm input: 4 Channel
Relay Output: 2 Channel
Playback and Backup
Sync Playback 16CH: 1/4/9 16/32CH: 1/4/9/16
Search Mode: Time /Date, Alarm, MD and Exact Search (accurate to second)
Playback Function: Play, Pause, Stop, Rewind, Fast play, Slow Play, Next File, Previous File, Next Camera, Previous Camera, Full Screen, Backup Selection, Digital Zoom
Backup Mode: USB Device/Network
Third-party Support
Third-party Support: Arecont Vision, Airlive, AXIS, Canon, Dynacolor, JVC, LG, Panasonic, Pelco, PSIA, Samsung, Sanyo, Sony, Watchnet and more
Network Interface: 1 RJ-45 Port (10/100/1000Mbps)
PoE: N/A
Network Function HTTP, HTTPS, TCP/IP, IPv4/IPv6, UPnP, SNMP, RTSP, UDP, SMTP, NTP, DHCP, DNS, IP Filter, PPPoE,DDNS, FTP, Alarm Server, IP Search (Support Dahua IP camera, DVR, NVS, etc.), Easy4IP
Max. User Access: 128 users
Smart Phone: iPhone, iPad, Android
Interoperability: ONVIF 2.4, SDK, CGI
Storage
Internal HDD: 2 SATA III Ports, Up to 10 TB capacity for each HDD
eSATA: N/A
Auxiliary Interface
USB: 2 USB Ports (1 Rear USB 3.0 , 1 Front USB 2.0 )
RS232: 1 Port, for PC Communication and Keyboard
RS485 1 Port, for PTZ Control
Electrical
Power Supply: Single, DC12V/4A
Power Consumption: <9.5W (Without HDD)
Fan: Smart fan, automatically adjust running speed
Environmental
Operating Condition: -10°C ~ +55°C (+14°F ~ +131°F), 86 ~ 106kpa
Storage Conditions: -20°C ~ +70°C (-4°F ~ +158°F), 0 ~ 90% RH
Construction
Dimensions: 1U, 375mm x 281.5mm x 56mm ; (14.8" x 11.1" x 2.2")
Net Weight: 1.6kg (3.5 lb) (without HDD)
Gross Weight: 3.2kg (7.1 lb) (without HDD)
Certifications
CE: EN55022, EN55024, EN50130-4, EN60950-1
FCC: Part 15 Subpart B, ANSI C63.4-2014
UL: UL 60950-1.
