TP-Link TL-SG1428PE 28-Port Gigabit Easy Smart Switch with 24-Port PoE+

$ 150.00 $ 145.00
  • Part Number: TL-SG1428PE
  • 24 10/100/1000Mbps RJ45 PoE+ ports switch with 2 Ethernet copper and  2 SFP fiber uplink ports
  • PoE power budget is up to 250 W*, making it ideal for small to medium business surveillance systems
  • Priority Mode helps to guarantee the quality of sensitive application like video monitoring
  • PoE Auto Recovery enables system self-healing to guarantee the stable operation of PoE-connected devices
  • QoS is for smooth internet-surfing experience and IGMP Snooping is capable of optimizing traffic for IPTV
  • Intelligent power management can protect the switch from overload
  • Warranty: 2Years on part
Order Now

Specification

  • Part Number: TL-SG1428PE
  • HARDWARE FEATURES
  • Standards and Protocols IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x
  • IEEE 802.3af, IEEE 802.3at, IEEE 802.1q, IEEE 802.1p
  • Interface:
  • 26 10/100/1000 Mbps RJ45 Ports
  • 2 Gigabit SFP Ports
  • Network Media:
  • 10BASE-T: UTP category 3, 4, 5 cable (maximum 100m)
  • EIA/TIA-568 100Ω STP (maximum 100m)
  • 100BASE-TX: UTP category 5, 5e cable (maximum 100m)
  • EIA/TIA-568 100Ω STP (maximum 100m)
  • 1000BASE-T: UTP category 5, 5e, 6 or above cable (maximum 100m)
  • EIA/TIA-568 100Ω STP (maximum 100m)
  • 1000BASE-X MMF, SMF
  • Fan Quantity: 2 Fans
  • Physical Security Lock: Yes
  • Power Supply: 100-240V AC, 50/60 Hz
  • PoE+ Ports(RJ45):
  • Standard: 802.3at/802.3af compliant
  • PoE+ Ports: 24 Ports
  • Power Supply: 250 W
  • Dimensions ( W x D x H ): 17.3 × 8.7 × 1.73 in (440 × 220 × 44 mm)
  • Mounting: 19" 1U rack mountable
  • Max Power Consumption:
  • 27 W (no power device connected)
  • 304.7 W (with 250W power device connected)
  • Max Heat Dissipation:
  • 92.1 BTU/h (no PD connected)
  • 1,039.0 BTU/h (with 250 W PD connected)
  • PERFORMANCE
  • Switching Capacity: 56 Gbps
  • Packet Forwarding Rate: 41.7 Mbps
  • MAC Address Table: 8K
  • Packet Buffer Memory: 4.1 Mbit
  • Jumbo Frame: 9 KB
  • SOFTWARE FEATURES
  • Quality of Service:
  • Support Port-based 802.1p/DSCP priority
  • Support 4 priority queues
  • Rate Limit
  • Storm Control
  • L2 Features:
  • IGMP Snooping V1/V2/V3
  • Static Link Aggregation
  • Port Mirroring
  • Cable Diagnostics
  • Loop Prevention
  • PoE Auto Recovery
  • VLAN:
  • Support up to 32 VLANs simultaneously (out of 4K VLAN IDs)
  • MTU/Port/Tag VLAN
  • Management: Web-Based GUI, Easy Smart Configuration Utility
  • Transmission Method: Store-And-Forward
  • OTHERS
  • Certification: CE, FCC, RoHS
  • Package Contents:
  • TL-SG1428PE
  • Power Cord
  • Installation Guide
  • Rackmount Kit
  • Rubber Feet
  • Environment:
  • Operating Temperature: 0°C~50°C (32°F~122°F)
  • Storage Temperature: -40°C~70°C (-40°F~158°F)
  • Operating Humidity: 10% ~ 90% non-condensing
  • Storage Humidity: 5%~90% non-condensing
  • Warranty: 2Years on part
