Hikvision IDS-7208HQHI-M1/E 8-ch 1080P 1U H.265 AcuSense DVR

~~$ 105.00~~ $ 95.00

Part Number: IDS-7208HQHI-M1/E
Deep learning based human and vehicle targets classification of Motion Detection 2.0
Deep learning-based perimeter protection
H.265 Pro+/H.265 Pro/H.265 video compression
HDTVI/AHD/CVI/CVBS/IP video inputs
Audio via coaxial cable
Up to 12-ch IP camera inputs (up to 6 MP)
Up to 1080p@15 fps encoding capability
Warranty: 1 Year on part

Order Now

Specification

Part Number: IDS-7208HQHI-M1/E
Motion Detection 2.0
Human/Vehicle Analysis: Deep learning-based motion detection 2.0 is enabled by default for all analog channels, it can classify human and vehicle, and extremely reduce false alarms caused by objects like leaves and lights; Quick search by object or event type is supported;
Perimeter Protection
Human/Vehicle Analysis: Up to 4-ch
Recording
Video Compression: H.265 Pro+/H.265 Pro/H.265/H.264+/H.264
Encoding Resolution: When 1080p Lite mode is not enabled: 4 MP Lite/3 MP/1080p/720p/VGA/WD1/4CIF/CIF; When 1080p Lite mode is enabled: 4 MP Lite/1080p Lite/720p Lite/VGA/WD1/4CIF/CIF
Frame Rate: Main stream: When 1080p Lite mode is not enabled: For 4 MP stream access: 4 MP Lite@15 fps; 1080p Lite/720p/WD1/4CIF/VGA/CIF@25 fps (P)/30 fps (N) For 3 MP stream access: 3 MP/1080p/720p/VGA/WD1/4CIF/CIF@15 fps For 1080p stream access: 1080p/720p@15 fps; VGA/WD1/4CIF/CIF@25fps (P)/30 fps (N) For 720p stream access: 720p/VGA/WD1/4CIF/CIF@25 fps (P)/30 fps (N) When 1080p Lite mode is enabled: 4 MP Lite@15 fps; 1080p Lite/720p Lite/VGA/WD1/4CIF/CIF@25 fps (P)/30 fps (N) Sub-stream: WD1/4CIF@12 fps; CIF@25 fps (P)/30 fps (N)
Video Bitrate: 32 Kbps to 6 Mbps
Dual-Stream: Support
Stream Type: Video, Video & Audio
Audio Compression:G.711u
Audio Bitrate: 64 Kbps
Video And Audio
IP Video Input: 2-ch (up to 10-ch): Enhanced IP mode on: 4-ch (up to 12-ch), each up to 4 Mbps Up to 6 MP resolution Support H.265+/H.265/H.264+/H.264 IP cameras
Analog Video Input: 8-ch: BNC interface (1.0 Vp-p, 75 Ω), supporting coaxitron connection
HDTVI Input: 4 MP, 3 MP, 1080p25, 1080p30, 720p25, 720p30, 720p50, 720p60
AHD Input: 4 MP, 1080p25, 1080p30, 720p25, 720p30
HDCVI Input: 4 MP, 1080p25, 1080p30, 720p25, 720p30
CVBS Input: Support
HDMI Output 1-ch, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz
VGA Output: 1-ch, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz
Video Output Mode: HDMI/VGA simultaneous output
Audio Input: 1-ch, RCA (2.0 Vp-p, 1 KΩ) 8-ch via coaxial cable
Audio Output: 1-ch, RCA (Linear, 1 KΩ)
Two-Way Audio: 1-ch, RCA (2.0 Vp-p, 1 KΩ) (using the first audio input)
Synchronous Playback: 8-ch
Network
Total Bandwidth: 96 Mbps
Remote Connection: 64
Network Protocol: TCP/IP, PPPoE, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, NFS, iSCSI, UPnP™, HTTPS, ONVIF
Network Interface: 1, RJ45 10/100 Mbps self-adaptive Ethernet interface
Wi-Fi: Connectable to Wi-Fi network by Wi-Fi dongle through USB interface
Auxiliary Interface
SATA: 1 SATA interface
Capacity: Up to 10 TB capacity for each disk
Alarm In/Out: N/A
USB Interface: Real panel: 2 × USB 2.0
General
Power Supply: 12 VDC, 1.33 A
Consumption:≤ 12 W (without HDD)
Working Temperature: -10 °C to +55 °C (+14 °F to +131 °F)
Working Humidity:10% to 90%
Dimension (W × D × H): 265 × 225 × 48 mm (10.4 × 8.9 × 1.9 inch) ≤ 1 kg (without HDD, 2.2 lb.)
Warranty: 1 Year on part
