Edgecore ECW5410-L Wi-Fi 5 Access Point

$ 328.00 $ 319.00
  • Part Number: ECW5410-L
  • 802.11ac Wave2
  • Concurrent Dual-Band 2.4GHz & 5GHz
  • 4x4:4 UL MU-MIMO
  • Support BLE
  • 1x GbE PoE WAN
  • 1x GbE LAN
  • Warranty: 1-Year on part.

Specification

  • Part Number: ECW5410-L
  • Channelization: 20 MHz, 40 MHz, 80 MHz
  • Frequency Band: 2.412- 2.472 GHz, 5.180- 5.825GHz
  • RF Output Power*1: 2.4GHz Up to 24 dBm*2; 5GHz Up to 24 dBm*2 (*1 RF output power aggregates across MIMO chains and doesn't contain antenna gain; *2 Maximum power is limited by local regulatory requirements)
  • Radio Chains: 4x 4 4
  • Mounting: Wall/Ceiling mount (Mounting kit included)
  • Console: 1x RJ-45 Port
  • USB: 1x USB 2.0 Port
  • LAN: 1x 10/100/1000Base-T Ethernet, Auto MDIX, RJ-45
  • DC Input: 12V / 2.5A
  • Configuration: Web User Interface (HTTP / HTTPS), SNMP v1, v2c, v3
  • Deployment: Standalone, Tunneled management by Edgecore EWS Gateway-Controller, IPv4 & IPv6 compatible, LLDP
  • Uplink: 1x 10/100/1000Base-T Ethernet, Auto MDIX, RJ-45 with 802.3at PoE
  • Type: 5 x Built-in PIFA (4x 2.4GHz, 5GHz, 1x Bluetooth Low Energy)
  • Gain: 3 dBi (2.4GHz), 5 dBi (5GHz), 3 dBi (BLE)
  • PoE: 802.3at compliant (PoE injector optional).
  • Weight: 0.61 g (1.34 lbs).
