APC EASY UPS BV 800VA AVR Outlet 230V (BV800i-MS)

$ 76.00 $ 70.00
  • Part Number: BV800I-MS
  • Lead time: Usually in Stock
  • Run time for load: 450W =0min 21s
  • Min-max: 45-450 W
  • Rated power in VA: 800 VA
  • Warranty: 2 years repair or replace

Specification

  • Part Number: BV800I-MS
  • Overview
  • Lead time: Usually in Stock
  • Main
  • Run time for load: 450W =0min 21s
  • Min-max: 45-450 W
  • Max. Capacity Used: 100 %
  • Main Input Voltage: 230 V
  • Main Output Voltage: 230 V
  • Rated power in W: 450 W
  • Rated power in VA: 800 VA
  • product or component type: Uninterruptible power supply (UPS)
  • Input Connection Type: NEMA 5-15P
  • output connection type: 4 universal receptacle
  • Cable length: 1.20 m
  • Number of cables: 1
  • Battery type: Lead-acid battery
  • Provided equipment: User manual
  • Batteries & Runtime
  • Run Time: View Runtime Graph
  • Efficiency: View Efficiency Graph
  • Number of battery filled slots: 0
  • Number of battery free slots: 0
  • Battery recharge time: 8 h
  • Battery voltage: 12 V
  • battery capacity: 7.0 Ah
  • Battery life: 3…5 year(s)
  • Replacement battery: APCRBC110
  • Extended runtime: 0
  • General
  • Number of power module free slots: 0
  • Number of power module filled slots: 0
  • Redundant: No
  • UPS size: WS
  • Physical
  • Colour: Black
  • Height: 9.25 cm
  • Width: 16.05 cm
  • Depth: 30.5 cm
  • Net weight: 5.3 kg
  • Mounting preference: No preference
  • mounting mode: Not rack-mountable
  • Two post mountable: 0
  • USB compatible: No
  • Input
  • Network frequency: 50/60 Hz +/- 5 Hz auto-sensing
  • Input voltage limits: 170...280 V
  • Output
  • Maximum configurable power in W: 450 W
  • Output frequency: 50/60 Hz +/- 1 Hz unsynchronised
  • UPS type: Line interactive
  • Wave type: Stepped approximation to a sinewave
  • Graph display: 1
  • Maximum configurable power in VA: 800 VA
  • Transfer time: 6 ms typical : 10 ms maximum
  • Conformance
  • Product certifications: CE
  • Standards
  • EN/IEC 62040-1:2019/A11:2021
  • EN/IEC 62040-2:2006/AC:2006
  • EN/IEC 62040-2:2018
  • Environmental
  • Ambient air temperature for operation: 0…40 °C
  • Relative humidity: 0…90 %
  • Operating altitude: 0...6667 ft
  • ambient air temperature for storage: -20…50 °C
  • Storage Relative Humidity: 0…90 %
  • Storage altitude: 0.00…15240.00 m
  • Acoustic level: 40 dBA
  • IP degree of protection: IP20
  • Communications & Management
  • Alarm: Alarm when on battery : distinctive low battery alarm : overload continuous tone alarm
  • Surge Protection and Filtering
  • Surge energy rate: 156 J
  • Packing Units
  • Unit Type of Package 1: PCE
  • Number of Units in Package 1: 1
  • Package 1 Height: 23.7 cm
  • Package 1 Width: 37.3 cm
  • Package 1 Length: 14.3 cm
  • Package 1 Weight: 5.6 kg
  • SCC14: 10731304338373
  • Warranty: 2 years repair or replace
