TP-Link TL-SG1016D 16-Port Gigabit Desktop/Rackmount Switch

$ 60.00 $ 55.00
  • Part Number: TL-SG1016D
  • 16x 10/100/1000Mbps ports
  • Innovative energy-efficient technology saves power consumption
  • Supports MAC address self-learning, Auto MDI/MDIX and Auto negotiation
  • Plug & play design
  • Warranty: 3 Years on part.
Order Now

Specification

  • Part Number: TL-SG1016D
  • HARDWARE FEATURES
  • Standards and Protocols: IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab , IEEE 802.3x
  • Interface: 16 10/100/1000Mbps RJ45 Ports (Auto Negotiation/Auto MDI/MDIX)
  • Network Media:
  • 10BASE-T: UTP category 3, 4, 5 cable (maximum 100m)
  • 100BASE-TX/1000BASE-T: UTP category 5, 5e or above cable (maximum 100m)
  • Fan Quantity: Fanless
  • Physical Security Lock: No
  • Power Supply: 100-240VAC, 50/60Hz
  • Power Consumption: Maximum: 9.26W (220V/50Hz)
  • Dimensions ( W x D x H ): 11.6*7.1*1.7 in. (294*180*44 mm)
  • Max Power Consumption: 9.95W(220V/50Hz)
  • Max Heat Dissipation: 33.93BTU/h
  • PERFORMANCE
  • Switching Capacity: 32Gbps
  • Packet Forwarding Rate: 23.8Mpps
  • MAC Address Table: 8K
  • Advanced Functions: Isolation Mode: Ports 1-14
  • Loop Prevention: Ports 1-16
  • Jumbo Frame: 10KB
  • Green Technology: Yes
  • Transfer Method: Store-and-Forward
  • OTHERS
  • Certification: FCC, RoHs
  • Package Contents: 16-Port Gigabit Desktop/Rackmount Switch
  • Power Cord
  • Installation Guide
  • Rackmount Kits
  • Rubber Feet
  • Environment:
  • Operating Temperature: 0℃~40℃ (32℉~104℉);
  • Storage Temperature: -40℃~70℃ (-40℉~158℉);
  • Operating Humidity: 10%~90% non-condensing;
  • Storage Humidity: 5%~90% non-condensin
  • Warranty: 3 Years on part.
