UniFi Pro Max 48 PoE 48-port Switch (USW-Pro-Max-48-PoE)

$ 1,644.00 $ 1,629.00
  • Part Number: USW-Pro-Max-48-PoE
  • (16) 2.5 GbE ports including (8) PoE+ and (8) PoE++
  • (32) GbE ports including (24) PoE+ and (8) PoE++
  • (4) 10G SFP+ ports
  • DC power backup ready
  • 720W total PoE availability
  • Warranty: 1 year on part.
Order Now

Specification

  • Part Number: USW-Pro-Max-48-PoE
  • General
  • Dimensions 442.4 x 399.6 x 43.7 mm (17.4 x 15.7 x 1.7")
  • Weight Without mounting brackets: 6.2 kg (13.7 lb)
  • With mounting brackets: 6.3 kg (13.9 lb)
  • Enclosure material SGCC steel
  • Hardware
  • Management interface Ethernet: In-Band
  • Networking interface (32) GbE RJ45 ports
  • (16) 1/2.5 GbE RJ45 ports
  • (4) 10G SFP+ ports
  • PoE interface (32) PoE/PoE+ (Pins 1, 2+; 3, 6-)
  • (16) 60W PoE++ (Pair A 1, 2+; 3, 6-) (Pair B 4, 5+; 7, 8-)
  • Total non-blocking throughput 112 Gbps
  • Switching capacity 224 Gbps
  • Power method Universal input, 100—240V AC, 50/60 Hz
  • USP RPS DC input
  • Power supply AC/DC, internal, 820W
  • Supported voltage range 100—240V AC
  • Max. power consumption 100W (Excluding PoE output)
  • Total available PoE 720W
  • Max. PoE wattage per port by PSE PoE: 15.4W
  • PoE+: 30W
  • PoE++: 60W
  • Voltage range PoE mode PoE: 44—57V
  • PoE+: 50—57V
  • LCM display (1) 1.3" touchscreen
  • Button Factory reset
  • Operating temperature -5 to 40° C (23 to 104° F)
  • Operating humidity 10 to 90% noncondensing
  • Certifications CE, FCC, IC
  • Switching Features
  • Layer 2 features:
  • IGMP snooping
  • STP / RSTP with priorities and port-level disable
  • Port isolation
  • Storm control
  • Voice VLAN
  • Port mirroring
  • LACP port aggregation
  • Multicast / broadcast rate limiting
  • MAC address blocking
  • Flow control
  • 802.1X control
  • Jumbo frames
  • Proprietary loop protection
  • DHCP snooping / guarding
  • Egress rate limit
  • LLDP-MED
  • Port restricted by MAC
  • Device isolation with ACLs
  • Layer 3 features:
  • DHCP for locally-managed networks
  • DHCP relay
  • Inter-VLAN routing between networks on same switch
  • Static routing between local networks
  • Network isolation with ACLs
  • Etherlighting
  • Ethernet Locating
  • Speed/link
  • Native VLAN/network
  • SFP+ Locating
  • Speed/link
  • Native VLAN/network
  • LEDs
  • System Status
  • RPS Status
  • Warranty: 1 year on part.
