TP-LINK TL-SF1024D 24-Port 10/100Mbps Desktop/Rackmount Switch

$ 50.00 $ 45.00
  • Part Number: TL-SF1024D
  • 24 10/100M RJ45 ports.
  • Innovative energy-efficient technology saves power up to 75%
  • Supports MAC address self-learning and auto MDI/MDIX.
  • Standard 13-inch steel case.
  • Warranty: 2 Years on part.
Order Now

Specification

  • Part Number: TL-SF1024D
  • HARDWARE FEATURES
  • Standards and Protocols: IEEE 802.3i, IEEE 802.3u, IEEE 802.3x
  • Interface: 24 10/100Mbps RJ45 Ports (Auto Negotiation/Auto MDI/MDIX)
  • Network Media:
  • 10BASE-T: UTP category 3, 4, 5 cable (maximum 100m)
  • 100BASE-TX: UTP category 5, 5e or above cable (maximum 100m)
  • Fan Quantity: Fanless
  • Physical Security Lock: Yes
  • Power Supply: External Power Adapter(Output: 9VDC/0.6A)
  • Power Consumption: Maximum: 3.2W
  • Dimensions ( W x D x H ): 11.6*7.1*1.7 in. (294*180*44 mm)
  • Mounting: Rack Mountable
  • Max Power Consumption: 3.19W(220V/50Hz)
  • Max Heat Dissipation: 10.88BTU/h
  • PERFORMANCE
  • Switching Capacity: 4.8Gbps
  • Packet Forwarding Rate: 3.57Mpps
  • MAC Address Table: 8K
  • Buffer Memory: 2Mb
  • Green Technology: Innovative energy-efficient technology saves power up to 75%
  • Transfer Method: Store-and-Forward
  • OTHERS
  • Certification: FCC, RoHS
  • Package Contents:
  • 24-Port 10/100Mbps Desktop/Rackmount Switch
  • Power Cord
  • Installation Guide
  • Rackmount Kit
  • Rubber Feet
  • Environment:
  • Operating Temperature: 0℃~40℃ (32℉~104℉)
  • Storage Temperature: -40℃~70℃ (-40℉~158℉)
  • Operating Humidity: 10%~90% non-condensing
  • Storage Humidity: 5%~90% non-condensing
  • Warranty: 2 Years on part.
