TP-Link Archer A6 AC1200 Wireless MU-MIMO Gigabit Router

~~$ 50.00~~ $ 45.00

Part Number: Archer A6
Supports 802.11ac standard
Simultaneous 2.4GHz 300 Mbps and 5GHz 867 Mbps connections for 1200 Mbps of total available bandwidth
4 external antennas and one internal antenna provide stable wireless connections and optimal coverage
Easy network management at your fingertips with TP-Link Tether
MU-MIMO achieves 2X efficiency by communicating with up to 2 devices at once
Beamforming technology delivers wider wireless coverage
Supports Access Point mode to create a new Wi-Fi access point
Warranty: 2 Years on part.

Order Now

Specification

Part Number: Archer A6
WIRELESS
Standards Wi-Fi 5
IEEE 802.11ac/n/a 5 GHz
IEEE 802.11n/b/g 2.4 GHz
WiFi Speeds AC1200
5 GHz: 867 Mbps (802.11ac)
2.4 GHz: 300 Mbps (802.11n)
WiFi Range:
3 Bedroom Houses
4× Fixed High-Performance Antennas
Multiple antennas form a signal-boosting array to cover more directions and large areas
Beamforming
Concentrates wireless signal strength towards clients to expand WiFi range
WiFi Capacity:
Medium
Dual-Band
Allocate devices to different bands for optimal performance
MU-MIMO
Simultaneously communicates with multiple MU-MIMO clients
Working Modes: Router Mode, Access Point Mode
SECURITY
Network Security:
SPI Firewall
Access Control
IP & MAC Binding
Application Layer Gateway
Guest Network:
-1× 5 GHz Guest Network
-1× 2.4 GHz Guest Network
VPN Server:
OpenVPN
PPTP
WiFi Encryption EU Version:
WPA
WPA2
WPA/WPA2-Enterprise (802.1x)
US, TW Version:
WPA
WPA2
WPA3
HARDWARE
Processor: Qualcomm CPU
Ethernet Ports: 1× Gigabit WAN Port, 4× Gigabit LAN Ports
Buttons: WPS/Wi-Fi Button
Power On/Off Button
Reset Button
Power: 12 V ⎓ 1 A
SOFTWARE
Protocols: IPv4, IPv6
OneMesh™: OneMesh™ Supported
Without replacing your existing devices or buying a whole new WiFi ecosystem, OneMesh™ helps you create a more flexible network that covers your entire home with TP-Link OneMesh™ products.
Learn More>
All OneMesh Products>
Parental Controls: URL Filtering, Time Controls
WAN Types:
Dynamic IP
Static IP
PPPoE
PPTP
L2TP
Quality of Service: QoS by Device
NAT Forwarding Virtual Servers
Port Forwarding
Port Triggering
DMZ
UPnP
IPTV:
IGMP Proxy
IGMP Snooping
Bridge
Tag VLAN
DHCP:
Address Reservation
DHCP Client List
Server
DDNS:
NO-IP
DynDNS
Management:
Tether App
Webpage
Check Web Emulator>
OTHER
System Requirements:
Internet Explorer 11+, Firefox 12.0+, Chrome 20.0+, Safari 4.0+, or other JavaScript-enabled browser
Cable or DSL Modem (if needed)
Subscription with an internet service provider (for internet access)
Certifications: FCC, CE, RoHS
Environment:
Operating Temperature: 0℃~40℃ (32℉ ~104℉)
Storage Temperature: -40℃~70℃ (-40℉ ~158℉)
Operating Humidity: 10%~90% non-condensing
Storage Humidity: 5%~90% non-condensing
TEST DATA
WiFi Transmission Power
CE EIRP:
<20dBm(2.4GHz)
<23dBm(5GHz)
FCC:
<30dBm(2.4GHz & 5GHz)
WiFi Reception Sensitivity
5GHz:
11a 6Mbps:-93dBm；11a 54Mbps:-78dBm；
11ac HT20 mcs8:69dBm;11ac HT40 mcs9:-65dBm;
11ac HT80 mcs9:-62dBm;
2.4GHz:
11g 54Mbps:-78dBm;
11n HT20 mcs7:-74dBm;
11n HT40 mcs7:-71dbm；
PHYSICAL
Dimensions (W×D×H): 9.1 × 5.7 × 1.4 in (230 × 144 × 35 mm)
Package Contents:
Wi-Fi Router Archer C6
Power Adapter
RJ45 Ethernet Cable
Quick Installation Guide
Warranty: 2 Years on part.
