UPS Prolink 1250VA PRO1202SFCU

$ 70.00 $ 67.00
  • Part Number: PRO1202SFCU
  • Capacity: 1250VA
  • Dimension (mm): 320 x 130 x 182 (D x W x H)
  • Weight (kg): 9.2
  • Nominal Voltage: 230VAC
  • Voltage Range: 140 – 300 VAC ± 5%
  • Nominal Frequency: 50 or 60Hz (Auto sensing)
  • Warranty: 1 Year on part

Specification

  • Part Number: PRO1202SFCU
  • Capacity: 1250VA
  • Dimension (mm): 320 x 130 x 182 (D x W x H)
  • Weight (kg): 9.2
  • INPUT
  • Nominal Voltage: 230VAC
  • Voltage Range: 140 – 300 VAC ± 5%
  • Nominal Frequency: 50 or 60Hz (Auto sensing)
  • OUTPUT
  • Voltage Regulation: ± 10%
  • Frequency: 50 or 60Hz ± 1Hz
  • Transfer Time (typical): 2 – 6ms
  • Waveform: Simulated Sinewave
  • BATTERY
  • Number of Battery: 12 V/8.2 Ah x 2
  • Recharge Time (typical): 2-4 hours recover to 90% capacity
  • ALARM & INDICATORS
  • LED Display: AC Mode – Green Lighting, Battery Mode – Yellow Flashing every 10 seconds, Overload – Red Flashing every second, Fault – Red Lighting
  • Sounding: Battery Mode – Sounding every 10 seconds, Low Battery – Sounding every second, Overload – Sounding every 0.5 second, Battery Replacement Alarm – Sounding every 2 seconds, Fault – Continously sounding
  • Warranty: 1 Year on part
