TP-Link Archer AX90 AX6600 Tri-Band Wi-Fi 6 Router

~~$ 270.00~~ $ 255.00

Part Number: Archer AX90
Faster AX6600 Tri-Band Wi-Fi - 4804 Mbps (5 GHz) + 1201 Mbps (5 GHz) + 574 Mbps (2.4 GHz).
Ultra Connectivity - 1× 2.5 Gbps WAN/LAN port + 1× 1 Gbps WAN/LAN port + 3× Gigabit LAN ports and two USB ports ensure max flexibility and boosted throughput.
Maximized Coverage - Eight high-gain antennas equipped with Beamforming ensure vast coverage.
More Devices with Less Lag - OFDMA and MU-MIMO technology deliver data to multiple devices, simultaneously.
TP-Link HomeShield - Enhanced security defends against the latest cyber threats.
Warranty: 3 Year on part

Order Now

Specification

Part Number: Archer AX90
WIRELESS
Standards:
Wi-Fi 6
IEEE 802.11ax/ac/n/a 5 GHz
IEEE 802.11ax/n/b/g 2.4 GHz
WiFi Speeds:
AX6600
5 GHz: 4804 Mbps (802.11ax, HE160)
5 GHz: 1201 Mbps (802.11ax)
2.4 GHz: 574 Mbps (802.11ax)
WiFi Range: 4 Bedroom Houses
8× Fixed High-Performance Antennas
Multiple antennas form a signal-boosting array to cover more directions and large areas
Beamforming
Concentrates wireless signal strength towards clients to expand WiFi range
High-Power FEM
Improves transmission power to strengthen signal coverage
4T4R
Multiple streams in the same band strengthen the fault tolerance in transmission
WiFi Capacity:
Very High
Tri-Band
Allocate devices to different bands for optimal performance
4×4 MU-MIMO
Simultaneously communicates with multiple MU-MIMO clients
OFDMA
Simultaneously communicates with multiple Wi-Fi 6 clients
Airtime Fairness
Improves network efficiency by limiting excessive occupation
DFS
Access an extra band to reduce congestion
8 Streams
Connect your devices to more bandwidth
Working Modes: Router Mode, Access Point Mode
HARDWARE
Processor:
1.5 GHz Quad-Core CPU
Ethernet Ports 1× 2.5 Gbps WAN/LAN Port
1× 1 Gbps WAN/LAN Port
3× 1 Gbps LAN Ports
USB Support:
1× USB 3.0 Port
1× USB 2.0 Port
Supported Partition Formats:
NTFS, exFAT, HFS , FAT32
Supported Functions:
Apple Time Machine
FTP Server
Media Server
Samba Server
Buttons Wi-Fi On/Off Button
Power On/Off Button
LED On/Off Button
WPS Button
Reset Button
Power: 12 V ⎓ 3.3 A
SECURITY
WiFi Encryption WPA
WPA2
WPA3
WPA/WPA2-Enterprise (802.1x)
Network Security:
SPI Firewall
Access Control
IP & MAC Binding
Application Layer Gateway
HomeShield Security
Real-Time IoT Protection
Malicious Site Blocker
Intrusion Prevention System
DDoS Attack Prevention
Home Network Scanne
Guest Network 1× 5 GHz-1 Guest Network
1× 5 GHz-2 Guest Network
1× 2.4 GHz Guest Network
VPN Server:
OpenVPN
PPTP
SOFTWARE
Protocols:
IPv4
IPv6
Service Kits: HomeShield
OneMesh™ :
OneMesh™ Supported: Without replacing your existing devices or buying a whole new WiFi ecosystem, OneMesh™ helps you create a more flexible network that covers your entire home with TP-Link OneMesh™ products.
Parental Controls: HomeShield Parental Controls
Custom Profiles
Professional Content Filter Library
Family Time
Bedtime
Off Time
Time Rewards
Family Online Time Ranking
Pause the Internet
Weekly and Monthly Reports
WAN Types:
Dynamic IP
Static IP
PPPoE
PPTP
L2TP
Quality of Service:
QoS by Device
Cloud Service: Auto Firmware Upgrade, TP-Link ID, DDNS
NAT Forwarding:
Port Forwarding
Port Triggering
DMZ
UPnP
Virtual Server
IPTV:
IGMP Proxy
IGMP Snooping
Bridge
Tag VLAN
DHCP:
Address Reservation
DHCP Client List
Server
DDNS:
TP-Link
NO-IP
DynDNS
Management:
Tether App
Webpage
PHYSICAL
Dimensions (W×D×H): 12.2 × 8.1 × 6.8 in, (311 × 207 × 174 mm)
Package Contents:
Wi-Fi Router Archer AX90
Power Adapter
RJ45 Ethernet Cable
Quick Installation Guide
OTHER
System Requirements:
Internet Explorer 11+, Firefox 12.0+, Chrome 20.0+, Safari 4.0+, or other javascript-enabled browser
Cable or DSL Modem (if needed)
Subscription with an internet service provider (for internet access)
Certifications: FCC, CE, RoHS
Environment:
Operating Temperature: 0℃~40℃ (32℉ ~104℉)
Storage Temperature: -40℃~70℃ (-40℉ ~158℉)
Operating Humidity: 10%~90% non-condensing
Storage Humidity: 5%~90% non-condensing
TEST DATA:
WiFi Transmission Power CE:
<20dBm{2.4GHz}
<23dBm{5.15GHz~5.35GHz}
<30dBm{5.47GHz~5.725GHz}
FCC:
<24dBm{5.47GHz~5.725GHz }
<30dBm{2.4GHz &5.15GHz~5.25GHz&5.725GHz~5.825GHz }
WiFi Reception Sensitivity 2.4GHz:
11n HT20 MCS0:-95dBm
11ax HE20 MCS11:-64dBm
11ax HE40 MCS11:-62dBm
5GHz-1:
11ac VHT20 MCS0:-92dBm
11ax HE20 MCS11:-61dBm
11ax HE40 MCS11:-58dBm
11ax HE80 MCS11:-55dBm
5GHz-2:
11ac VHT20 MCS0:-95dBm
11ax HE20 MCS11:-61dBm
11ax HE40 MCS11:-58dBm
11ax HE80 MCS11:-55dBm
11ax HE160 MCS11:-53dBm
Warranty: 3 Year on part
