Eaton UPS 5E1600UI-EA 1600VA/900W

~~$ 205.00~~ $ 195.00

Part Number: Eaton 5E1600UI-EA
Rating (kVA/kW): 1600VA/900W
Topology: Line-interactive
Form factor: Tower
Input nominal voltage: 230V default (220/230/240V)
Output nominal voltage: 230V
Battery rating: 12 V / 7 Ah
Product Weight: 8.89 kg
Warranty: 2years on Part.

Order Now

Specification

Part Number: Eaton 5E1600UI
GENERAL SPECIFICATIONS
Product Name: Eaton 5E Gen2 UPS
EAN: 3553340704321
Product Length/Depth: 330 mm
Product Height: 180 mm
Product Width: 133 mm
Product Weight: 8.89 kg
PRODUCT SPECIFICATIONS
Special features:
- Automatic Voltage Regulation (AVR)
- Saves space with a compact tower design
- HID-compliant USB port, for automatic integration with major operating systems (Windows/Mac OS/Linux)
Type: UPS
Topology: Line-interactive
Form factor: Tower
Construction type: Free standing model
Color: Black
VA rating: 1600 VA
Wattage: 900 W
Rack mounting kit: No
Package contents:
- (2) IEC-IEC output cables
- Quick start
- Safety instructions
Surge protection: Yes
Internal bypass: No
Hot swap power: No
Auto shutdown function: Yes
Primary frequency - max: 63 Hz
Primary frequency - min: 45 Hz
Input connection: C14
Input nominal voltage: 230V default (220/230/240V)
Nominal frequency: 50/60 Hz
Input frequency range: 45-63 Hz
Receptacle: (6) C13
Number of Outputs C13: 6
Voltage: 230V
Output nominal voltage: 230V
Feed type: 1
Voltage type: AC
Runtime graph: View runtime graph
Battery management: Automatic battery test, deep-discharge protection, cold-start capable
Battery rating: 12 V / 9 Ah
Battery type: Sealed, lead-acid
Extended battery capability: No
Communication: USB port (HID compliant)
Expansion slots: No
Ethernet interface: No
Includes network card: No
Software compatibility: Eaton UPS Companion (enables safe system shutdown, energy usage metering and configuration of UPS settings)
User interface: LEDs
Type of interface: USB
Potential free switch contact: No
Relative humidity: 0-90% non-condensing
Temperature range: 0° to 40°C (32° to 104°F)
Operating temperature - max: 40 °C
Operating temperature - min: 0 °C
Output apparent power: 1600 VA
Input voltage - max: 300 V
Input voltage - min: 140 V
Output voltage - max: 257 V
Output voltage - min: 195 V
Secondary frequency - max: 60 Hz
Secondary frequency - min: 50 Hz
Battery quantity: 2
Efficiency: 95
Input voltage range: 140-300 V
Output frequency: 50/60 Hz
Output voltage range: 195-257 V
Phase (input): 1
Phase (output): 1
Warranty: 2-years on Part.
