Vertiv Liebert GXT5 ON-LINE 3000VA 230V (GXT5-3000IRT2UXL)

~~$ 1,420.00~~ $ 1,410.00

Part Number: GXT5-3000IRT2UXL
Rating: 750VA/750W
Rated Voltage: 230VAC
Rated Frequency: 50/60Hz
Frequency Range: 40 to 70 Hz
Power Factor: ≥0.99
Warranty: 3 Years on part.

Order Now

Specification

Part Number: GXT5-3000IRT2UXL
Input
Rating: 750VA/750W
Rated Voltage: 230VAC
Rated Frequency: 50/60Hz
Frequency Range: 40 to 70 Hz
Power Factor: ≥0.99
Output
Nominal Voltage: 200/208/220/230/240 VAC
Waveform Sine wave
Inverter Overload Capability:
>200% minimum 250 mS,
150 to 200% for 2 seconds;
125 to 150% for 50 seconds;
105 to 125% for 60 seconds
Efficiency in Online Mode: Up to 94%
Inverter Bypass: Up to 98%
Output Receptacles: 6x EN60320/C13; 1x EN60320/C19
Internal Battery
Rated Voltage: 72Vdc
Charger Current: Nominal 2.2 A; Maximum 8A
Type: Valve-regulated, non-spillable, lead acid
Quantity x V x Rating: 6 x 12V x 9.0Ah
End Cell Voltage: 1.67 V/cell (discharge voltage per cell will be from 1.67 Vdc to 1.90 Vdc, can be selected by PARAMSET)
Floating Voltage: Equalize charge: 2.35 V/cell; Float charge: 2.27 V/cell
Battery Voltage Range: 60 Vdc to 84.6 Vdc
Internal Battery Backup Time (Approximate)
10% Load Capacity: 70 mins
20% Load Capacity: 31.5 mins
30% Load Capacity: 18.5 mins
40% Load Capacity: 12.5 mins
50% Load Capacity: 9 mins
60% Load Capacity: 7 mins
70% Load Capacity: 6 mins
80% Load Capacity: 4.5 mins
90% Load Capacity: 4 mins
100% Load Capacity: 3 mins
General
Operating Temperature, °C: Full power up to 40 ºC, (up to 50 ºC with derating)
Storage Temperature, °C: - 15 to + 40
Relative Humidity: 0 to 95% non-condensing
Operating Elevation: Up to 3,000 m at 25°C without derating
Audible Noise: <46 dBA, at 1 meter from sides, <43 dBA, at 1 meter from rear
Safety: IEC62040-1:2008 version, GS mark; CE: UL1778 5th Edition and CSA 22.2 No 107.1
EMI/EMC/C-Tick EMC:
EN 62040-2:2006;
EN 61000-3-3:2013;
EN 61000-3-3:2013
Transportation: ISTA Procedure 1 A
Surge Immunity: ANSI C62.41 Category B IEC 61000-4-5 Surges/Lighting
Dimensions (mm): 540 (w) x 430 (d) x 85 (h)
Weight: 28.5kg
Warranty: 3 Years on part
