APC Smart-UPS SRT 8000VA RM 230V SRT8KRMXLI

~~$ 4,010.00~~ $ 3,980.00

Part Number: SRT8KRMXLI
Includes: CD with software , Documentation CD , Installation guide , Rack Mounting brackets , Rack mounting hardware , Rack Mounting support rails , Temperature Probe , USB cable , Warranty card , Web/SNMP Management Card
Warranty: 3 Years repair or replace (excluding battery) and 2 Years for battery.

Specification

Part Number: SRT8KRMXLI
Output power capacity 8.0 KWatts / 8.0 kVA
Max Configurable Power (Watts) 8.0 KWatts / 8.0 kVA
Nominal Output Voltage 230V
Output Voltage Distortion Less than 2%
Output Frequency (sync to mains) 50/60Hz +/- 3 Hz
Other Output Voltages 220, 240
Load Crest Factor 3 : 1
Topology Double Conversion Online
Waveform type Sine wave
(4) IEC 320 C19 (Battery Backup)
(6) IEC 320 C13 (Battery Backup)
(1) Hard Wire 3-wire (H N + G) (Battery Backup)
(3) IEC Jumpers (Battery Backup)
Bypass Internal Bypass (Automatic and Manual)
Nominal Input Voltage 230V , 400V 3PH
Input frequency 40 - 70 Hz (auto sensing)
Input Connections Hard Wire 3 wire (1PH+N+G), Hard Wire 5-wire (3PH + N + G)
Input voltage range for main operations 160 - 275V
Input voltage adjustable range for mains operation 100 - 275 (half load), 173 - 476 (half load)V
Other Input Voltages 220, 240, 380, 415
Battery type Maintenance-free sealed Lead-Acid battery with suspended electrolyte :leakproof
Typical recharge time 1.5hour(s)
Replacement BatteryAPCRBC140
Expected Battery Life (years) 3 - 5
RBC Quantity 2
Extendable Run Time 1
Extended Run OptionsAPC-Smart-UPS-SRT-8000VA-RM-230V
RuntimeView Runtime Graph View Runtime Chart
EfficiencyView Efficiency Graph.
Warranty: 3 Years repair or replace (excluding battery) and 2 Years for battery.
