UniFi Switch Pro Max 48-Port Gigabit Layer 3 (USW-Pro-Max-48)

$ 850.00 $ 839.00
  • Part Number: USW-Pro-Max-48
  • (16) 2.5 Gigabit RJ45 ports
  • (32) Gigabit RJ45 ports
  • (4) 10G SFP+ ports
  • DC power backup ready
  • A 48-port, Layer 3 Etherlighting™ switch with 2.5 GbE.
  • Warranty: 1 Year on part.
Order Now

Specification

  • Part Number: USW-Pro-Max-48
  • Mechanical
  • Dimensions: 442 x 325 x 44 mm (17.4 x 12.8 x 1.7")
  • Weight: Without mounting brackets: 4.8 kg (10.6 lb)
  • Weight: With mounting brackets: 4.9 kg (10.8 lb)
  • Enclosure material: SGCC steel
  • Hardware
  • Management interface: Ethernet In-Band
  • Networking interface: (32) GbE RJ45 ports
  • Networking interface: (16) 1/2.5 GbE RJ45 ports
  • Networking interface: (4) 10G SFP+ ports
  • Total non-blocking throughput: 112 Gbps
  • Switching capacity: 224 Gbps
  • Forwarding rate: 166.656 Mpps
  • Power method: (1) Universal input, 100—240V AC, 50/60 Hz & (1) USP-RPS DC input
  • Power supply: AC/DC, internal, 100W
  • Supported voltage range: 100—240V AC
  • Max. power consumption: 100W
  • LCM display: (1) 1.3" touchscreen
  • Button: Factory reset
  • Ambient operating temperature: -5 to 40° C (23 to 104° F)
  • Ambient operating humidity: 10 to 90% noncondensing
  • Certifications: CE, FCC, IC
  • Switching Features
  • * Layer 2 features:
  • -IGMP snooping
  • -STP / RSTP with priorities and port-level disable
  • -Port isolation
  • -Storm control
  • -Voice VLAN
  • -Port mirroring
  • -LACP port aggregation
  • -Multicast / broadcast rate limiting
  • -MAC address blocking
  • -Flow control
  • -802.1X control
  • -Jumbo frames
  • -Proprietary loop protection
  • -DHCP snooping / guarding
  • -Egress rate limit
  • -LLDP-MED
  • -Port restricted by MAC
  • -Device isolation with ACLs
  • * Layer 3 features:
  • -DHCP for locally-managed networks
  • -DHCP relay
  • -Inter-VLAN routing between networks on same switch
  • -Static routing between local networks
  • -Network isolation with ACLs
  • Etherlighting™
  • * Ethernet:
  • -Locating
  • -Speed/link
  • -Native VLAN/network
  • * SFP+ :
  • -Locating
  • -Speed/link
  • -Native VLAN/network
  • LEDs
  • System: Status
  • RPS: Status
  • Application Requirements
  • UniFi Network: Version 8.0.24 and later
  • Warranty: 1 Year on part.
