Ubiquiti UniFi Access Point U6 In-Wall (U6-IW) Wall-Mounted WiFi 6 access point
$255.00
- Part Number: U6 In-Wall
- Wall-mounted WiFi 6 AP with 6 spatial streams and a built-in 4‑port switch ideal for single-room coverage in hospitality environments.
- Warraty: 1 year on ports.
Contact for Price & Stock
Delivery 25 Provinces
Official Warranty
100% Genuine Product
Tech Support
Specifications
- Part Number: U6 In-Wall
- Overview
- Dimensions: 139.7 x 96 x 31.2 mm (5.5 x 3.8 x 1.3")
- WiFi Standard: WiFi 6
- Spatial Streams: 6
- Coverage Area: 115 m² (1,250 ft²)
- Max. Client Count: 300+
- Uplink: GbE
- Mounting: Wall (Mount Included)
- Power Method: PoE, PoE+ (Required for PoE output)
- Performance
- MIMO
- 5 GHz: 4 x 4 (DL/UL MU-MIMO)
- 2.4 GHz: 2 x 2 (DL/UL MU-MIMO)
- Max. Data Rate:
- 5 GHz: 4.8 Gbps (BW160)
- 2.4 GHz: 573.5 Mbps (BW40)
- Antenna Gain:
- 5 GHz: 5.9 dBi
- 2.4 GHz: 5 dBi
- Max. TX Power:
- 5 GHz: 26 dBm
- 2.4 GHz: 22 dBm
- Max. BSSIDs: 8 per Radio
- Supported Data Rates:
- 802.11ax (WiFi 6): 7.3 Mbps to 4.8 Gbps (MCS0 - MCS11 NSS1/2/3/4, HE 20/40/80/160)
- 802.11ac (WiFi 5): 6.5 Mbps to 3.4 Gbps (MCS0 - MCS9 NSS1/2/3/4, VHT 20/40/80/160)
- 802.11n: 6.5 Mbps to 600 Mbps (MCS0 - MCS31, HT 20/40)
- Hardware
- Max. Power Consumption: 13W (Excluding PoE output)
- Networking Interface: (1) Data-in: GbE RJ45 port, (4) Data-out: GbE RJ45 ports
- Weight: 460 g (1 lb)
- Management
- Ethernet: Bluetooth
- Built-In Switch: (4) GbE ports with (1) PoE output
- Enclosure Material: Plastic, aluminum
- Mount Material: Aluminum
- LEDs
- System: White/Blue
- Channel Bandwidth: HT 20/40, VHT 20/40/80/160, HE 20/40/80/160 (MHz)
- NDAA Compliant: ✓
- Certifications: CE, FCC, IC
- Operating Frequency
- US/CA: 2400 - 2472 MHz
- U-NII-1: 5150 - 5250 MHz
- U-NII-2A: 5250 - 5350 MHz
- U-NII-2C: 5470 - 5725 MHz
- U-NII-3: 5725 - 5850 MHz
- Worldwide:
- 2400 - 2483.5 MHz
- 5150 - 5725 MHz
- Ambient Operating Temperature: -30 to 60° C (-22 to 140° F)
- Ambient Operating Humidity: 5 to 95% noncondensing
- Warraty: 1 year on ports.
