TP-Link TD-W8970 300Mbps Wireless N Gigabit ADSL2+ Modem Router

~~$ 50.00~~ $ 45.00

Part Number: TD-W8970
All-in-One Device: ADSL2 Modem, NAT Router, 4-Gigabit-Port Switch and Wireless N Access Point
300Mbps Wireless speed and Gigabit Ethernet ports, ideal for multiple HD video streams
Versatile Connectivity: ADSL, Ethernet WAN or 3G/4G modem for multiple Internet connection types
One USB 2.0 port for storage sharing, printer sharing, FTP Server, Media Server and 3G/4G Modem
Warranty: 3 Year on part.

Order Now

Specification

Part Number: TD-W8970
HARDWARE FEATURES
Interface
4 10/100/1000Mbps RJ45 Ports
1 RJ11 Port
1 USB 2.0 Port
Button:
1 Power On/Off Button
1 WPS Button
1 Wi-Fi On/Off Switch
1 RESET Button
External Power Supply: 12VDC/1.5A
IEEE Standards: IEEE 802.3, 802.3u, 802.3ab
ADSL Standards: Full-rate ANSI T1.413 Issue 2
ITU-T G.992.1(G.DMT), ITU-T G.992.2(G.Lite)
ITU-T G.994.1 (G.hs)
ITU-T G.995.1
ADSL2 Standards ITU-T G.992.3 (G.dmt.bis), ITU-T G.992.4(G.lite.bis)
ADSL2 Standards ITU-T G.992.5
Dimensions ( W x D x H ): 8.9x5.5x1.3 in.(225x140x32.5mm)
Antenna Type: Omni directional, Detachable, Reverse SMA
Antenna Gain: 2 x 5dBi
WIRELESS FEATURES
Wireless Standards: IEEE 802.11b, 802.11g, 802.11n
Frequency: 2.400-2.4835GHz
Transmit Power: <20dBm(EIRP)
Wireless Security: Support 64/128 bit WEP, WPA /WPA2, WPA-PSK/WPA2-PSK, Wireless MAC Filtering
SOFTWARE FEATURES
Quality of Service: WMM, Bandwidth Control (IP QoS)
Security: NAT Firewall, SPI Firewall, MAC / IP / URL Filtering
IPv6: IPv6 and IPv4 dual stack
Supported IPv6 Tunnels: DS-Lite, 6RD, 6 to 4
Supported IPv6 Connection Type: PPPoEv6, DHCPv6, Static IPv6
Management:
Web Based Configuration(HTTP)
Remote management
Telnet management
Command Line Interface
SSL for TR-069
SNMP V1/V2C
Web Based Firmware Upgrade
CWMP(TR-069)
Port Forwarding: Virtual server, Port Triggering, UPnP, DMZ, Manage Control
VPN Pass-Through: PPTP, L2TP, IPSec Pass-through
ATM/PPP Protocols: ATM Forum UNI3.1/4.0
PPP over ATM (RFC 2364)
PPP over Ethernet (RFC2516)
IPoA (RFC1577/2225)
PVC - Up to 8 PVCs
Advanced Features:
Guest Network, Parental Control, Wireless Schedule
Traffic Shaping(ATM QoS) UBR, CBR, VBR-rt, VBR-nrt
Dynamic Host Configuration Protocol (DHCP), DHCP relay
Network Address Translation (NAT)
PVC/Ethernet Port Grouping
Static Routing, RIP v1/v2 (optional)
DNS Relay, DDNS
USB Sharing: Storage Sharing, FTP Server, Media Server, Print Server
IGMP: IGMP snooping V1/V2/V3, IGMP Multicast
IPSec VPN 10 IPSec VPN Tunnels
LAN-to-LAN
Main, Aggressive Negotiation Mode
DES, 3DES, AES128, AES192, AES256 Encryption Algorithm
MD5, SHA1 Authentication Algorithm
Manual, IKE Key Management Mode
Dead Peer Detection (DPD)
Perfect Forward Secrecy (PFS)
OTHERS
Certification: CE, FCC, RoHS, IPv6
System Requirements: Microsoft® Windows® 98SE, NT, 2000, XP, Vista or Windows 10/8.1/7, MAC® OS, NetWare®, UNIX® or Linux.
Environment:
Operating Temperature: 0°C~40°C (32°F~104°F)
Storage Temperature: -40°C~70°C (-40°F~158°F)
Operating Humidity: 10%~90% non-condensing
Storage Humidity: 5%~90% non-condensing
Warranty: 3 Year on part.
