User Management: User level: administrator, regular user
Log: System, Recording, User
Date & Time: Time Zone, Manual, Automatic Sync NTP, Daylight Saving Time
Fan: Yes
Security: Encrypted streaming & control
VIDEO
Inputs: 16 channels
AUDIO
Audio Input/Output: 3.5 mm Line in x1, 3.5 mm Line out x1
Two-way Communication: Supported
Audio Format: G.711
DISPLAY
Interface: HDMI x 1 (4K Max), VGA x1 (1080P)
Resolution: 3840 x 2160, 1920 x 1080, 1280 x 1024,1024 x 768
Display Split: 1 x 1, 2 x 2, 3 x 3, 4 x 4, 1 + 7,customs
OSD: Time OSD, channel OSD
Stream Application: 1x1: 1ch 4K MAX 2x2: 2MP in, 4x1080P 2x2: >2MP, Camera Stream 2
3x3: and above: Camera Stream 2
PTZ Operation: Direction control, home,iris, preset, patrol
VIDEO DETECTION AND ALARMS
Event: Camera: Camera Alarm In, Motion detection, Camera disconnection,Tampering detection, Smart motion detection, intrusion, Crowd detection, multi-loitering System: System Alarm in/out, Disk failure, Disk full
Event Action: Video recording, Send email, Buzzer, FTP, Camera Alarm Out, PTZ-Preset, System Alarm Out,Send video to full screen
Alarm Input: 8
Alarm Out: 2
RECORDING
Compression: H.265 HEVC smart codec/H.264
Resolution: Up to 3840 x 2160
Frame Rate: 30 fps
Recording Mode: Continuous, Manual, Event
Max Pre-Event Recording Buffer Size:
Main Stream: 8Mb
Sub Stream: 4Mb
Post-Event Recording Interval: 30 s (Max. 60 s)
Recording Stream: Support main stream and sub stream simultaneous recording
Search Mode: Time search ,Event Search, Video clip
Playback Function: Regular (play, pause, stop), play backwards, next frame, Go back 30 seconds, Go forward 30 seconds ,speed control, timeline, timeline scale,Digital zoom,snapshot,back up
