Edgecore EWS5204 Wireless LAN Controller

$ 23,100.00 $ 22,875.00
  • Part Number: EWS5204
  • Wireless LAN Controller
  • Managed up to 1,000 APs
  • Up to 30,000 local accounts
  • 2 x GbE or 2 x 1GbE SFP WAN port
  • 6 x GbE or 2 x 1GbE SFP LAN port
  • 2 x USB 3.0 port
  • Rack Mount
  • Warranty: 1-Year on part.

Specification

  • Part Number: EWS5204
  • Access Points: Up to 1,000 Managed Edgecore APs
  • Local Accounts: Up to 250 Managed Switches
  • On-Demand Accounts: Up to 30,000 Local Accounts
  • Max. Number of Online Users: 10,000; Switchable
  • Input: 100-240 VAC, 50/60 Hz
  • Console: 1x RJ-45
  • WAN: 2x 10/100/1000Base-T Ethernet, Auto-MDIX, RJ-45
  • WAN: 2x 100/1000 SFP
  • Billing Quota Types: By duration; By Traffic Volume
  • Authentication: 802.1X, UAM (browser-based), IP or MAC-based
  • Authentication Servers: Local, On-demand, Guest, RADIUS, LDAP, NT Domain, SIP, POP3
  • Tunneling Protocols: IPSec, IKEv2
  • High Availability: N+1 Redundancy with automatic synchronization
  • Internet Protocols Supported: IPv4, IPv6
  • LAN: 6x 10/100/1000Base-T Ethernet, Auto-MDIX, RJ-45
  • LAN: 2x 100/1000 SFP
  • USB: 2x USB3.0
  • Operating Temperature: 0°C (32°F) to 40°C (104°F)
  • Weight: 5.2kg (11.46 lbs).
