Hikvision Camera DS-2DE5225IW-AE

~~$ 410.00~~ $ 395.00

Part Number: DS-2DE5225IW-AE
High quality imaging with 2 MP resolution
Excellent low-light performance via powered-by-DarkFighter technology
Clear imaging against strong back lighting due to 120 dB WDR technology
Pan and tilt ability enables camera to monitor zones of interest
25x optical zoom allows for closer viewing of subjects in expansive areas
Up to 150m IR range ensures safety at night
Water and dust resistant (IP66).
Warranty: 1 Year on part

Order Now

Specification

Part Number: DS-2DE5225IW-AE
Camera:
Image Sensor: 1/2.8" HD progressive scan CMOS
Effective Pixels: 1920(H)x1080(V)
Signal System: PAL/NTSC
Minimum Illumination: Color: 0.005 Lux @(F1.6, AGC ON),B/W: 0.001Lux @(F1.6, AGC ON),0 Lux with IR
White Balance: Auto/Manual/ATW (Auto-Tracking White Balance)/Indoor/Outdoor/Fluorescent Lamp/Sodium Lamp
AGC: Auto/Manual
BLC: ON/OFF
HLC: Support
Smart defog: Support
WDR: 120dB
Shutter Time: 1-1/10,000s
Day& Night: ICR
Digital Zoom: 16X
Privacy Masking: 24 privacy masks programmable; optional multiple colors and mosaics
Auto Focus: Auto / Semi-automatic / Manual
Lens:
Focal Length: 4.8 mm to 120 mm, 25× optical zoom
Zoom Speed: Approx. 3.6 s (optical lens, wide-tele)
Angle of View: Horizontal field of view: 57.6° to 2.5° (Wide-Tele)
Vertical field of view: 34.4° to 1.4° (Wide-Tele)
Diagonal field of view: 64.5° to 2.9° (Wide-Tele)
Minimum Working Distance: 10-1,500mm(Wide-Tele)
Aperture Range: F1.6 to F3.5
Pan & Tilt:
Pan Range: 360°endless
Pan Speed: Configurable, from 0.1°/s to 120°/s
Preset speed: 120°/s
Tilt Range: -15°-90° (Auto Flip )
Tilt Speed: Configurable, from 0.1°/s to 80°/s
Preset Speed: 80°/s
Proportional Zoom: Rotation speed can be adjusted automatically according to zoom multiples
Number of Preset: 300
Patrol: 8 patrols, up to 32 presets per patrol
Pattern: 4 pattern scans, record time over 10 minutes for each scan
Power-off Memory: Support
Park Action: Preset/Pattern Scan/Patrol Scan/Auto Scan/Tilt Scan/Random Scan/Frame Scan/Panorama Scan
PTZ Position Display: ON/OFF
Infrared:
IR irradiation distance: 150m
IR irradiation angle: Adjustable by zoom
Network:
Ethernet: 10Base -T, /100Base-TX, RJ45 Connector
Max.Image Resolution: 1920×1080
Main Stream: 50Hz:25fps (1920×1080,1280×960,1280×720), 50fps (1280×960,1280×720) ;,60Hz:30fps(1920×1080,1280×960,1280×720), 60fps (1280×960,1280×720)
Sub Stream: 50Hz: 25fps(704×576, 640x480,352×288); 60Hz: 30fps(704×480, 640x480,352×240)
Third Stream: 50Hz: 25fps(1920×1080, 1280×960, 1280×720, 704×576, 640x480,352×288),60Hz: 30fps(1920×1080, 1280×960, 1280×720, 704×576, 640x480,352×288)
Video Compression: Main Stream: H.265+/H.265/H.264+/H.264
Sub-Stream: H.265/H.264/MJPEG
Third Stream: H.265/H.264/MJPEG
ROI encoding: Support 4 areas with adjustable levels
Audio Compression: G.711alaw/G.711ulaw/G.722.1/G.726/MP2L2/PCM
Audio Mode: OFF/Audio input/Audio output
Protocols: IPv4/IPv6, HTTP, HTTPS, 802.1x, Qos, FTP, SMTP, UPnP, SNMP, DNS, DDNS, NTP, RTSP, RTCP, RTP, TCP, UDP, IGMP, ICMP, DHCP, PPPoE, Bonjour
No. of Simultaneous Users: Up to 20 users
Three-Stream: Support
Mini SD Card: Built-in memory card slot, support Micro SD/SDHC/SDXC, up to 256 GB
User/Host Level: Up to 32 users, 3 levels: Administrator, Operator and User
Security Measures: User authentication (ID and PW), host authentication (MAC address)
Hik-Connect: Support
Client GUI:
Client: iVMS-4200, iVMS-4500, iVMS-5200, Hik-Connect
Web Browser: IE 8 to 11, Chrome 31.0 to 44, Firefox 30.0 to 51
General:
Menu Language: English
Power Supply: 24 VAC and PoE+
Power Consumption: Max.: 30 W (Max. 10 W for IR)
Working Temperature/Humidity: -30 ℃-65℃(-22℉-149℉)(outdoor)
90% or less
Protection Level: IP66 standard (outdoor dome),TVS 4,000V lightning protection, surge protection and voltage transient protection
Mounting: Various mounting modes optional
Material: ADC 12, PC, PC+10%GF
Dimensions: Φ 208 mm × 345 mm (Φ 8.19" × 13.58")
Weight (approx.): Approx. 3.3 kg (7.28 lb)
Warranty: 1 Year on part
