Huawei eKit S210-8P2J 8Port POE Switch with 2*2.5GE SFP ports
$129.00
- Huawei eKit S210-8P2J
- 8 x 10/100/1000BASE-T PoE+ ports
- 2 x 2.5GE SFP ports
- Packet forwarding rate: 19.5Mpps
- Switching capacity: 26 Gbit/s
- 128W total PoE supply
- Warranty: 2-years on part.
Contact for Price & Stock
Delivery 25 Provinces
Official Warranty
100% Genuine Product
Tech Support
Specifications
- Huawei eKit S210-8P2J
- 8 x 10/100/1000BASE-T PoE+ ports
- 2 x 2.5GE SFP ports
- Packet forwarding rate: 19.5Mpps
- Switching capacity: 26 Gbit/s
- 128W total PoE supply
- Long-term operating relative humidity [RH]: 5% RH to 95% RH, non-condensing
- Power supply mode: Power adapter
- Input voltage range [V] Power adapter input: 170 V AC to 264 V AC; 47 Hz to 63 Hz
- Power supply surge protection [kV]: ±4 kV in differential mode and ±4 kV in common mode
- Heat dissipation mode: Natural heat dissipation
- PoE+ power interfaces: 8
- Full load PoE power consumption 30W (802.3at): 4
- Full load PoE power consumption 15.4W (802.3af): 8
- GE RJ45 8 (PoE+): (1G/100M/10M)
- 2.5G SFP: 2 (2.5G/1G/100M)
- PoE: Supported
- Maximum PoE power consumption [W]: 128
- Certification: EMC certification Safety certification Manufacturing certification
- Chassis material: Metal
- Static power consumption [W]: 7.15
- Dimensions without packaging (H x W x D) [mm(in.)]: Basic dimensions (excluding the parts protruding from the body): 43.6 mm x 195 mm x 160 mm (1.72 in. x 7.68 in. x 6.30 in.) Maximum dimensions (the depth is the distance from ports on the front panel to the parts protruding from the rear panel): 43.6 mm x 195 mm x 166.2 mm (1.72 in. x 7.68 in. x 6.54 in.)
- Dimensions with packaging (H x W x D) [mm(in.)]: 116.0 mm x 285.0 mm x 300.0 mm (4.57 in. x 11.22 in. x 11.81 in.)
- Installation type: Desk mounting,Wall mounting
- Weight without packaging [kg(lb)]: 1.60 kg (3.53 lb)
- Weight with packaging [kg(lb)]: 2.08 kg (4.59 lb)
- Typical power consumption [W]: 16.74
- Maximum power consumption [W]: - Without PoE: 14.60 W (device), 17.59 W (device + adapter) - Full PoE load: 161.02 W (PoE: 128 W)
- Long-term operating temperature [°C(°F)]: –5°C to +45°C (23°F to 113°F) at an altitude of 0 to 1800 m (0 to 5905.44 ft.)
- Warranty: 2-years on part.
