Emerson/Vertiv GXT5 On-Line 5000VA/5000W 230V (GXT5-5000IRT5UXLN)
$2,510.00
- Part Number: GXT5-5000IRT5UXLN
- Input AC Parameters
- Operating Frequency, Nom: 50 or 60 Hz (Factory default is 50 Hz )
- Factory Default Voltage: 230 VAC
- Operating Voltage Range Without Battery Operation: 176 to 288 VAC (100 to 176 VAC with power derating)
- Maximum Allowable Voltage: 288 VAC
- Input Frequency Without Battery Operation: 40 to 70 Hz
- Warranty: 3 Years on part.
Contact for Price & Stock
Delivery 25 Provinces
Official Warranty
100% Genuine Product
Tech Support
Specifications
- Part Number: GXT5-5000IRT5UXLN
- Input AC Parameters
- Operating Frequency, Nom: 50 or 60 Hz (Factory default is 50 Hz )
- Factory Default Voltage: 230 VAC
- Operating Voltage Range Without Battery Operation: 176 to 288 VAC (100 to 176 VAC with power derating)
- Maximum Allowable Voltage: 288 VAC
- Input Frequency Without Battery Operation: 40 to 70 Hz
- Output AC Parameters
- AC-AC Efficiency: 94% 94% 94.5% 95%
- User-configurable Voltage: 200/208/220/230/240 VAC
- Factory Default Voltage: 230 VAC
- Frequency: 50 Hz or 60 Hz, Nominal
- Waveform: Pure Sinewave
- Output Power Connection: Output terminal block
- Main Mode Overload: >150% minimum 200 ms, 125 – 150% for 60 seconds; 105 – 125% for 5 minutes; ≤ 105% continuous
- Internal Battery
- Charger Current: 2.25 A (default), maximum 5 A 2.25 A (default), maximum 8 A
- Type: Valve-regulated, non-spillable, lead acid
- Qty x V x Rating: 2 x 8 x 12V x 9.0 AH
- Back-up Time at Full Load: 7 5,5 3,5 2
- Back-up Time at Half Load: 18,5 14,5 9,5 7
- Bypass Protection Limits
- Upper-limit Selections: + 10%, + 15%, + 20%; default + 10%.
- Lower-limit Selections: - 10%, - 15%, - 20%; default - 15%
- Disable-bypass Operation: When the input frequency prevents synchronous operation
- General
- Operating Temperature, °C: Full power up to 40 ºC (up to 50 ºC with derating)
- Storage Temperature, °C: - 15 to + 40
- Relative Humidity: 0 – 95% non-condensing
- Operating Elevation: Up to 3,000 m (9,842.5 ft) at 25°C (77°F) without derating
- Audible Noise: <55 dBA
- Safety: UL-1788 (Fifth Edition),C-UL listed, IEC 62040-1: 2017 Edition 2.0, EN 62040-1:2008+A1:2013
- EMI/EMC/C-Tick EMC: IEC/EN/AS 62040-2 2nd Ed (Cat 2 – Table 6); FCC Part 15 (Class A)
- CISPR22 Class A (RFI)
- ESD: IEC/EN EN61000-4-2, Level 4, Criteria B
- Radiated Susceptibility: IEC/EN EN61000-4-3, Level 3, Criteria A
- Electrical Fast Transient: IEC/EN EN61000-4-4, Level 4, Criteria B
- Surge Immunity: IEC/EN EN61000-4-5, Level 4, Criteria A; ANSI C62.41 Category B
- Transportation: ISTA Procedure 1E
- Dimensions and Weight
- Dimensions (mm) Unit, W×D×H: 430×630×217
- Unit Weight (kg): 70.8 74.5
- POD
- Model Number: PD5-CE6HDWRMBS PD5-CE10HDWRMBS
- Amp Rating: 50 A 63 A
- Includes: Two ICE320 C19 16 A / 250 V Sockets,
- Six C13 10 A / 250 V Sockets
- Four ICE320 C19 16 A / 250 V Sockets,
- Four C13 10 A / 250 V Sockets
- Warranty: 3 Years on part.
