Ubiquiti UniFi Switch Pro 48 PoE, 600W 48Ports (USW-Pro-48-POE)
$1,299.00
- Part Number: USW-Pro-48-POE
- (40) GbE, PoE+ RJ45 ports
- (8) GbE, PoE++ RJ45 ports
- (4) 10G SFP+ ports
- (1) USP RPS DC input for power redundancy
- 600W total PoE availability
- Warranty: 1 year on Part.
Contact for Price & Stock
Delivery 25 Provinces
Official Warranty
100% Genuine Product
Tech Support
Specifications
- Part Number: USW-Pro-48-POE
- Mechanical
- Dimensions: 442.4 x 399.6 x 43.7 mm (17.42 x 15.73 x 1.72")
- Weight: Without Brackets: 6.25 kg (13.78 lb)
- With Brackets: 6.34 kg (13.98 lb)
- Hardware
- Networking Interface: (48) 10/100/1000 RJ45 Ports, (4) 1/10G SFP+ Ethernet Ports
- Management Interface: Ethernet In-Band
- Total Non‑Blocking Throughput: 88 Gbps
- Switching Capacity: 176 Gbps
- Forwarding Rate: 130.944 Mpps
- Power Method
- Universal Input: 100-240VAC/50-60 Hz
- USP RPS DC Input: 52VDC, 11.54A; 11.5VDC, 5.22A
- Power Supply: AC/DC, Internal, 660W
- Supported Voltage Range: 100 to 240VAC
- Max. Power Consumption (Excluding PoE Output): 60W
- LEDs
- System: Status
- RJ45 Data Ports: PoE; Speed/Link/Activity
- SFP+ Data Ports: Link/Activity
- ESD/EMP Protection: Air: ± 16 kV, Contact: ± 12 kV
- Shock and Vibration: ETSI300-019-1.4 Standard
- Operating Temperature: -5 to 40° C (23 to 104° F)
- Operating Humidity: 10 to 90% Noncondensing
- Certifications: CE, FCC, IC
- PoE
- Total Available PoE: 600W
- PoE Interfaces
- Ports 1-40: PoE/PoE+ (pins 1, 2+; 3, 6-)
- Ports 41-48: 60W PoE++ (Pair A 1, 2+; 3, 6-) (Pair B 4 , 5+; 7, 8-)
- Max. PoE Wattage per Port by PSE
- PoE+: 32W
- PoE++: 64W
- Voltage Range PoE Mode: 44-57V
- Voltage Range PoE+ Mode: 50-57V
- Warranty: 1 year on Part.
