Ubiquiti UniFi Pro (USW-Pro-24-POE) 24-Port POE (400W), 2x 10G SFP+ ports, Layer3 Switch
$895.00
- Part Number: USW-Pro-24-POE
- Switch Pro 24 PoE
- 16x 802.3at PoE+ ports
- 8x 802.3bt PoE++ ports
- 2x 10G SFP+ ports
- 400W total PoE supply
- Layer 3, PoE switch with (24) GbE RJ45
- Warranty: 1-year on part.
Contact for Price & Stock
Delivery 25 Provinces
Official Warranty
100% Genuine Product
Tech Support
Specifications
- Part Number: USW-Pro-24-POE
- Overview
- Dimensions: 442 x 285 x 44 mm (17.4 x 11.2 x 1.7")
- Port Layout:
- 1 GbE RJ45: 24 (16 PoE+; 8 PoE++) (1G/100M/10M)
- 10G SFP+: 2 (10G/1G)
- Max. PoE Output: Up to PoE++
- Total PoE Availability: 400W
- Redundancy: DC Power Backup
- Layer 3: Yes
- Form Factor: Rack mount (1U)
- Performance
- Switching Capacity: 88 Gbps
- Total Non-Blocking Throughput: 44 Gbps
- Forwarding Rate: 65 Mpps
- Supported VLANs: 1,000
- MAC Address Table Size: 16,000
- L3 Table Size
- ARP Entries: 768
- IPv4 Routes: 64
- Packet Buffer Size: 2 MB
- Access Lists:
- IPv4: 128
- MAC: 128
- Hardware
- PoE Ports: PoE+
- 16: PoE++
- 8: Max. PoE Wattage per Port by PSE
- PoE: 15.4W
- PoE+: 30W
- PoE++: 64W
- Max. Power Consumption: 50W (Excluding PoE Output)
- Max. Power Consumption: 450W (Including PoE Output)
- Power Method: (1) Universal input, 100—240V AC, 50/60 Hz
- Power Method: (1) USP RPS DC input
- Power Input Method: AC input
- Power Supply: AC/DC, internal, 450W
- Supported Voltage Range: 100—240V AC
- Management: Ethernet, AR
- Heat Dissipation (Excluding PoE Output): 170.6 BTU/hr
- Weight: Without mounting brackets: 4.3 kg (9.5 lb)
- Weight: With mounting brackets: 4.4 kg (9.7 lb)
- Enclosure Material: SGCC steel
- Supported Rack Depth: 400~1200 mm (15.7-47.2")
- LCM Display: 1.3" touchscreen
- ESD Protection: Air: ± 16kV, contact: ± 12kV
- Ambient Operating Temperature: -5 to 40° C (23 to 104° F)
- Ambient Operating Humidity: 10 to 90% noncondensing
- NDAA Compliant: Yes
- Certifications: CE, FCC, IC, Anatel: 13790-20-08356
- UniFi Network: Version 5.10.5 and later.
