Uniview UAC-T112-F28-W 2MP ColourHunter HD Fixed Turret Analog Camera
$25.00
- Part Number: UAC-T112-F28-W
- 2MP high quality image
- TVI/AHD/CVI/CVBS
- Supports white light illumination, 24/7 full-color imaging
- Supports 180° horizontal flip, 180° vertical flip
- OSD configuration menu, easy to operate
- IP67 waterproof and dustproof design, high reliability
- OSD configuration menu in 11 languages
- 3-Axis
- Warranty: 1-year on Part.
Contact for Price & Stock
Delivery 25 Provinces
Official Warranty
100% Genuine Product
Tech Support
Specifications
- Part Number: UAC-T112-F28-W
- Camera
- Max Resolution: 2 MP
- Sensor Size: 1/3.0" CMOS
- Min. Illumination: 0.01 lux (F1.6, AGC ON), 0 lux (white light on)
- Lens
- Focus: 2.8 mm, 4.0 mm
- Lens Mount: M12
- Angle of View (H): 100.9°, 82.5°
- Angle of View (V): 56.5°, 42.1°
- Angle of View (D): 121.8°: 98.6°
- Illuminator
- Illuminator Number: One white-light illuminator
- Illumination Distance: 20m
- Lifetime: ≥ 60000 hours
- Video
- Resolution: 1080P: 1920(H)×1080(V), 720P: 1280(H) ×720(V)
- Frame Rate: TVI: 1080P@25fps (default), 1080P@30fps; 720P@25fps, 720P@30fps
- AHD: 1080P@25fps, 1080P@30fps; 720P@25fps, 720P@30fps
- CVI: 1080P@25fps, 1080P@30fps; 720P@25fps, 720P@30fps
- CVBS: PAL, NTSC
- Shutter Time: PAL: 1/25 s-1/50000 s, NTSC: 1/30 s-1/50000 s
- Image
- Exposure Mode: Four modes: Global (default), BLC, HLC, DWDR
- Digital Noise Reduction: 2D/3D
- White Balance: Two modes: Auto (default), Manual
- WDR: DWDR
- Flip: Supports 180°horizontal flip, 180°vertical flip
- Interface
- Power Interface: 5.5 mm Power Interface
- Video Output: BNC, supports TVI/AHD/CVI/CVBS
- Operating Environment
- Temperature: -30 ℃ to 60 ℃ (-22 ℉ to 140 ℉)
- Humidity: ≤ 95% RH (non-condensing)
- Surge Protection: 4 KV for power, 4 KV for video output interfaces
- General
- Power: DC 12 V ± 25%: DC 12 V±25%
- Power Consumption: MAX 2.4W
- Mount: Wall Mount, Pole Mount, Corner Mount, Pendant Mount
- Wall Mount, Pole Mount, Corner Mount, Pendant Mount
- Dimensions: Φ118mm*96mm (diameter*height)
- Material: Graphene + Plastic
- OSD Menu Language: 11 Languages: English, German, Spanish (Latin America), French, Italian, Japanese, Korean, Polish, Portuguese (Brazil), Russian, Turkish
- Certification
- EMC: CE-EMC (EN 55032, EN 61000-3-3, EN IEC 61000-3-2, EN 55035), FCC (FCC 47 CFR part15 B)
- Safety: CE-LVD (EN 62368-1)
- Environment: CE-RoHS (2011/65/EU; (EU) 2015/863); WEEE (2012/19/EU)
- Protection: IP67 (IEC 60529)
- Weight: 205g(0.452lb).
