Uniview UAC-B125-AF28LM 5MP LightHunter HD IR Fixed Mini Bullet Analog Camera
$33.00
- Part Number: UAC-B125-AF28LM
- High quality imaging with 5MP resolution
- TVI/AHD/CVI/CVBS
- Supports IR-cut filter with auto-switch (ICR)
- LightHunter monitoring with high-sensitivity sensor
- Supports 180° horizontal flip, 180° vertical flip
- OSD configuration menu, easy to operate
- IP67 waterproof and dustproof design, high reliability
- OSD configuration menu in 11 languages
- Built-in microphone for high quality audio transmission via coaxial cables
- Warranty: 1-year on Part.
Contact for Price & Stock
Delivery 25 Provinces
Official Warranty
100% Genuine Product
Tech Support
Specifications
- Part Number: UAC-B125-AF28LM
- Camera
- Max Resolution: 5 MP
- Sensor Size: 1/2.7" CMOS
- Min. Illumination: 0.005 lux (F1.6, AGC ON)
- 0 lux (IR on)
- Lens
- Focus: 2.8 mm, 4.0 mm
- Lens Mount: M12
- Angle of View (H): 109.1°, 91.3°
- Angle of View (V): 60.9°, 46.1°
- Angle of View (D): 126.7°, 109.6°
- Illuminator
- Illuminator Number: Two IR illuminators
- Illumination Distance: 40m
- Lifetime: ≥ 60000 hours
- Video
- Resolution: 5MP@25fps: 2880(H)×1620(V); 5MP@20fps: 2592(H)×1944(V); [email protected]: 2592(H)×1944(V)
- 4MP: 2560(H)×1440(V), 1080P: 1920(H)×1080(V)
- Frame Rate TVI: 5MP@20fps (default), [email protected], 4MP@25fps, 4MP@30fps, 1080P@25fps, 1080P@30fps
- AHD: 5MP@20fps, 4MP@25fps, 4MP@30fps, 1080P@25fps, 1080P@30fps
- CVI: 5MP@25fps, 4MP@25fps, 4MP@30fps, 1080P@25fps, 1080P@30fps
- CVBS: PAL, NTSC
- Shutter Time: PAL: 1/25s-1/50000s，NTSC: 1/30s-1/50000s
- Image
- Exposure Mode: Four modes: Global (default), BLC, HLC, DWDR
- Day/Night: Three modes: Auto (default), Day, Night
- Digital Noise Reduction: 2D
- White Balance: Two modes: Auto (default), Manual
- WDR: DWDR
- Smart IR: Support
- Flip: Supports 180°horizontal flip, 180°vertical flip
- Digital Defog: N/A
- Audio
- Built-in Mic: Support
- Camera Audio: TVI: 5MP@20fps, [email protected], 4MP@25fps, 4MP@30fps, 1080P@25fps, 1080P@30fps
- CVI: 5MP@25fps, 4MP@25fps, 4MP@30fps
- Interface
- Power Interface: 5.5 mm Power Interface
- Video Output: BNC, supports TVI/AHD/CVI/CVBS
- Operating Environment
- Temperature: -30°C to 60°C (-22°F to 140°F)
- Humidity: ≤ 95% RH (non-condensing)
- Surge Protection: 4 KV for power, 4 KV for video output interfaces
- Ingress Protection: IP67
- General
- Power: DC 12 V ± 25%
- Power Consumption: MAX 3.4W
- Mount: Corner Mount, Pole Mount
- Dimensions: 154mm*66mm*66mm (L*W*H)
- Material: Graphene + Metal + Plastic
- Weight: 240g(0.53lb).
