TP-Link ES205GP Omada 5-Port Gigabit Easy Managed Switch with 4-Port PoE+
$30.00
- Part Number: B14VFKG
- 5× 10/100/1000Mbps RJ45 ports (4× 802.3at/af-compliant PoE+)
- 65W Power Budget, with up to 30W for each PoE port*
- Easy to Use: Supports plug-and-play for instant connectivity and simple configuration for additional features
- Centralized Cloud Management via the web or the Omada app†
- Up to 250m PoE**, QoS△, PoE Auto Recovery‡, and Port Isolation for reliable surveillance networking
- Automatic Loop Prevention, VLAN, and IGMP Snooping
- Fanless design for silent operation
- Durable metal casing and desktop/wall mounting design
- Warranty: 3 Years on Part.
Contact for Price & Stock
Delivery 25 Provinces
Official Warranty
100% Genuine Product
Tech Support
Specifications
- Part Numer: ES205GP
- HARDWARE FEATURES
- Interface
- - 5× 10/100/1000 Mbps RJ45 Ports (Ports 1–4 Support 802.3af PoE and 802.3at PoE+)
- - Auto-Negotiation/Auto MDI/MDIX
- Fan Quantity: Fanless
- Installation: Desktop & Wall Mount
- Physical Security Lock: √
- Power Supply: DC Power Adapter (Output: 53.5V DC / 1.31A)
- PoE Ports (RJ45):
- - Standard: 802.3af PoE and 802.3at PoE+ compliant
- - PoE Ports: 4 ports
- - PoE Budget: 65 W available for all PoE+ ports, 30W max per port
- - PoE Auto Recovery‡
- - Up to 250m PoE transmission distance**
- Dimensions ( W x D x H ): 3.9 × 3.9 × 1.0 in (100 × 98 × 25 mm)
- Surge Protection: ±6kV
- PERFORMANCE
- Switching Capacity: 10 Gbps
- Packet Forwarding Rate: 7.4 Mpps
- MAC Address Table: 8K
- Packet Buffer Memory: 4 Mbit
- Jumbo Frame: 15 KB
- SOFTWARE FEATURES
- Quality of Service:
- - Port-based/802.1p/DSCP QoS
- - 8 Priority Queues
- - Priority Schedule Mode
- - WRR (Weighted Round Robin)
- - Queue Weight Config
- - Bandwidth Control
- - Port-Based Rating Limit
- - Storm Control
- - Multiple Control Modes (kbps/pps)
- - Broadcast/Multicast/Unknown-Unicast Control△
- L2 Features:
- - Static Link Aggregation
- - Loop Prevention / Loopback Detection
- - Flow Control
- - 802.3x Flow Control
- - Mirroring
- - Port Mirroring
- - One-to-One
- - Many-to-One
- - Ingress/Egress/Both
- - Port Statistics
- - Port Mirror Status
- - Traffic Statistics
- - 802.1ab LLDP
- L2 Multicast:
- - IGMP Snooping
- - IGMP v1/v2/v3 Snooping
- - Fast Leave
- VLAN:
- - MTU VLAN
- - Port-Based VLAN
- - 802.1Q Tag VLAN
- - Max 32 VLAN Groups
- - 4K VID
- Transmission Method: Store-And-Forward
- Management Features:
- Omada App: Yes. Requires the use of Omada Hardware Controller, Omada Cloud-Based Controller, or Omada Software Controller.
- Centralized Management:
- - Omada Cloud-Based Controller
- - Omada Hardware Controller
- - Omada Software Controller
- Cloud Access: Yes. Requires the use of Omada Hardware Controller, Omada Cloud-Based Controller, or Omada Software Controller.
- Zero-Touch Provisioning Yes. Requires the use of Omada Cloud-Based Controller
- Management Features:
- - Web-based GUI
- - DHCP Client
- - Cable Diagnostics
- - Automatic Device Discovery†
- - Batch Configuration†
- - Batch Firmware Upgrading†
- - Unified Configuration†
- OTHERS
- Certification: FCC, CE, RoHS
- Package Content:
- - ES205GP
- - Power Adapter
- - Power Cord
- - Rubber Feet
- - Installation Guide
- Environment:
- - Operating Temperature: 0℃~40℃ (32℉~104℉)
- - Storage Temperature: -40℃~70℃ (-40℉~158℉)
- - Operating Humidity: 10%~90% non-condensing
- - Storage Humidity: 5%~90% non-condensing
- Warranty: 3 Years on Part
