TP-Link TL-SG2210MP JetStream 10-Port Gigabit Smart PoE Switch with 8-Port PoE+
$160.00
- Part Number: TL-SG2210MP
- 150 W PoE Budget: 8× 802.3at/af-compliant PoE+ ports with a total power supply of 150 W*.
- Full Gigabit Ports: 8× gigabit PoE+ ports and 2× gigabit SFP Slots provide high-speed connections.
- Integrated into Omada SDN: Zero-Touch Provisioning (ZTP)**, Centralized Cloud Management, and Intelligent Monitoring.
- Centralized Management: Cloud access and Omada app for ultra convenience and easy management.
- Robust Security Strategies: IP-MAC-Port Binding, ACL, Port Security, DoS Defend, Storm Control, DHCP Snooping, 802.1X, Radius Authentication, and more.
- Optimize Voice and Video Applications: L2/L3/L4 QoS and IGMP snooping.
- Warranty: 3 years on part.
Contact for Price & Stock
Delivery 25 Provinces
Official Warranty
100% Genuine Product
Tech Support
Specifications
- HARDWARE FEATURES
- Standards and Protocols: IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE802.3z, IEEE 802.3ad, IEEE 802.3x, IEEE 802.3af, IEEE 802.3at, IEEE 802.3az, IEEE 802.1d, IEEE 802.1s, IEEE 802.1w, IEEE 802.1q, IEEE 802.1x, IEEE 802.1p
- Interface:
- • 8× 10/100/1000 Mbps RJ45 Ports, all supporting PoE+ (Auto-Negotiation/Auto MDI/MDIX)
- • 2× 100/1000 Mbps SFP Slots
- Network Media:
- • 10BASE-T: UTP/STP category 3, 4, 5 cable (maximum 100m)
- • 100BASE-TX/1000Base-T: UTP/STP category 5, 5e or above cable (maximum 100m)
- • 100BASE-FX: MMF, SMF
- • 1000BASE-X: MMF, SMF
- Fan Quantity: 1
- Physical Security Lock: Yes
- Power Supply: 100-240V AC, 50/60Hz
- PoE Ports (RJ45):
- • Standard: 802.3at/af compliant
- • PoE+ Ports: 8 Ports
- • PoE Power Budget: 150 W*
- Dimensions ( W x D x H ): 11.6 x 7.1 x 1.7 in (294 x 180 x 44 mm)
- Mounting: Rackmount/Desktop
- Max Power Consumption:
- • V1: 173.9 W (110 V/60 Hz) (with 150 W PD connected); 12.2 W (110 V/60 Hz) (no PD connected)
- • V2: 169.5 W (220 V/50Hz) (with 150 W PD connected)
- • V3: 175.3 W (110 V/60Hz) (with 150 W PD connected)
- • V4: 174.2 W (110V/60Hz) (with 150 W PD connected)
- Max Heat Dissipation:
- • V1: 41.63 BTU/h (with no PD connected); 539.35 BTU/h (with 150 W PD connected)
- • V2: 578.42 BTU/hr (220V/50 Hz) (with 150 W PDconnected)
- • V3: 597.8 BTU/hr (110 V/60 Hz) (with 150 W PD connected)
- • V4: 594.46 BTU/hr (110V/60Hz) (with 150 W PD connected)
- PERFORMANCE
- Switching Capacity: 20 Gbps
- Packet Forwarding Rate: 14.9 Mpps
- MAC Address Table: 8K
- Packet Buffer Memory: 4.1 Mbit
- Jumbo Frame: 9 KB
