APC Easy UPS On-Line 1000VA/900W, Rackmount 2U, 230V 3x IEC C13 outlets (SRV1KRIRK-E)
$389.00
- Part Number: SRV1KRIRK-E
- UPS type: Double conversion online
- Main Input Voltage: 230 V
- Main Output Voltage: 230 V
- Rated power in W: 900 W
- Rated power in VA: 1000 VA
- Input Connection Type: IEC 60320 C14
- Output connection type: 3 IEC 60320 C13
- Net weight: 11.5 kg
- Warranty: 2 years on repair or replace.
Contact for Price & Stock
Delivery 25 Provinces
Official Warranty
100% Genuine Product
Tech Support
Specifications
- Part Number: SRV1KRIRK-E
- Overview
- Presentation: High quality, Double-conversion On-line UPS designed for essential power protection needs even in the most unstable power conditions.
- Lead timeL Usually in Stock
- Main
- Run time for load: 900 W
- Min-max: 90-900 W: 3min 12s
- Max. Capacity Used: 100 %
- Main Input Voltage: 230 V AC 1 phase
- Input voltage: 220 V, 240 V
- Input Connection Type: IEC 60320 C14
- Input voltage limits: 110...285 V 40% load, 180...285 V full load
- Network frequency: 40...70 Hz auto sensing
- Output voltage: 230 V AC 1 phase
- Output voltage: 220 V & 240 V
- Rated power in W: 900 W
- rated power in VA: 1000 VA
- Output connection type: 3 IEC 60320 C13
- Bypass type: Internal bypass (automatic and manual)
- Crest factor: 3 : 1
- Harmonic distortion: 3 %
- Maximum configurable power in VA: 1000 VA
- Maximum configurable power in W: 900 W
- UPS type: Double conversion online
- Wave type: Sine wave
- Efficiency: 88 % (full load)
- Output frequency: 50/60 Hz +/- 3 Hz sync to mains
- Complementary
- Additional information: Configurable for 220 : 230 or 240 nominal output voltage
- Battery type: Lead-acid internal included
- Control panel: Multifunction LCD status and control console
- Free slots: 1
- Alarm: Alarm when on battery : distinctive low battery alarm : overload continuous tone alarm
- UPS connectivity: Serial port
- USB port: Available expansion slot
- Surge energy rate: 945 J
- Number of rack unit: 2U
- Cable length: 1.5 m
- Number of cables: 1
- Colour: Black (RAL 7010)
- Height: 86 mm
- Width: 438 mm
- Depth: 312 mm
- Net weight: 11.5 kg
- Mounting location: Front
- Mounting preference: Lower
- Mounting mode: Rack-mounted
- USB compatible: Yes
- Mounting position: Horizontal
- Mounting mode: Rack-mounted with included kit
- Max runtime: 3 min
- Number of power module filled slots: 0
- Number of power module free slots: 0
- Redundant: No
- Range of product: Easy UPS On-Line
- Product or component type: Uninterruptible power supply (UPS)
- Environment
- Product certifications: CE, UKCA, TISI
- Standards:
- - EN/IEC 62040-1:2019/A11:2021
- - EN/IEC 62040-2:2006/AC:2006
- - EN/IEC 62040-2:2018
- Ambient air temperature for operation: 0…40 °C
- Ambient air temperature for storage: -20…50 °C
- Storage altitude: 0…15000 m
- IP degree of protection: IP20
- Relative humidity: 0…95 % non-condensing
- Storage Relative Humidity: 0…95 % non-condensing
- Acoustic level: 50 dBA
- Heat dissipation: 380 Btu/h
- Operating altitude: 0...3000 m
- Batteries & Runtime
- Battery type: Lead-acid battery
- Battery voltage: 24 V
- Extended runtime: 0
- Number of battery filled slots: 0
- Number of battery free slots: 0
- Battery recharge time: 4 h
- Replacement battery: APCRBCV200
- Battery charger power: 30 W rated
- Packing Units
- Unit Type of Package 1: PCE
- Number of Units in Package 1: 1
- Package 1 Height: 42.000 cm
- Package 1 Width: 80.000 cm
- Package 1 Length: 60.000 cm
- Package 1 Weight: 21.990 kg.
