UPS PROLINK 1KVA PRO801ERS, Online Rack mount, LCD, 8xIEC, USB, RS232 port, PF0.9 (battery 9AHx2) 2Y
- Part Number: PRO801ERS
- Capacity: 1KVA: 1000VA / 900W
- Battery: 12V/9Ah x 2pcs
- UPS type: Rack / Tower
- Input phase: Single phase with ground
- Front panel: Status LED, function keys, LCD display
- Communication: Smart RS232, USB port and Emergency Power Off (EPO)
- LCD indicators: Load level, battery level, AC mode, battery mode, bypass mode, and fault
- Warranty: 2-years on part.
Contact for Price & Stock
Delivery 25 Provinces
Official Warranty
100% Genuine Product
Tech Support
Specifications
- Part Number: PRO801ERS
- *GENERAL
- - UPS Type: Rack / Tower
- - Phase: Single phase with ground
- - Rating (VA): 1000
- - Nominal Power (W): 900
- - Dimension (mm): 410 x 438 x 88 [2U] (D x W x H)
- - Weight (kg): 11.6 Kg
- *INPUT
- - Connection Type: IEC 320-C14
- - Nominal Voltage: 200/208/220/230/240 VAC
- - Voltage Range: 55-150 VAC ± 5%, 110-300 VAC ± 5%
- - Frequency Range: 40Hz ~ 70Hz
- - Power Factor: ≧0.99
- *OUTPUT
- - Connection Type: 8 x IEC 320-C13
- - Nominal Voltage: 200/208/220/230/240 VAC
- - Voltage Regulation: ±1%
- - Frequency Range (Synchronized Range): 47 ~ 53 Hz or 57 ~ 63 Hz
- - Frequency Range (Batt. Mode): 50 Hz ± 0.5% or 60Hz ± 0.5%
- - Current Crest Ratio: 5:1 (max.)
- - Harmonic Distortion: ≦2% THD (Linear load), ≦4% THD (Non-linear load)
- *ALARM & INDICATORS
- - Battery Mode: Sounding every 4 seconds
- - Low Battery: Sounding every second
- - Overload: Sounding twice every second
- - Fault: Continuously sounding
- - LCD: Load level, Battery Level, AC mode, Battery mode, Bypass mode and Fault
- CONNECTIVITY, CONTROL & MONITORING
- - Front panel: Status LED, Function keys, LCD display
- - Communication: Smart RS232*, USB Port, Emergency Power Off (EPO)
- *BATTERY
- - Type: 12V / 9Ah
- - Numbers: 2
- - Typical Recharge Time: 4 hours recover to 90% capacity.
