Advidia M-NVR-32CH 32ch 8HDDs 4K Network Video Recorder (NVR)
$1,660.00
- Part Number: M-NVR-32CH
- Support H.265/H.264 video formats
- Support cloud Firmware upgrade
- NDAA Compliant
- 32-channel input
- Support 2-ch HDMI, 1-ch VGA independent outputs
- HDMI1 and HDMI2 up to 4K (3840x2160) resolution
- Up to 4K resolution recording
- Support RAID 0, 1,5, 6, 10
- 8 SATA HDDs, up to 10TB for each HDD
- Support N+1 Hot spare
- ANR technology to enhance the storage reliability when the network is disconnected
- Support mainstream camera of ONVIF conformance (Profile G, S, T) and RTSP protocols
- Warranty: 1-Year on part.
Contact for Price & Stock
Delivery 25 Provinces
Official Warranty
100% Genuine Product
Tech Support
Specifications
- Part Number: M-NVR-32CH
- Support H.265/H.264 video formats
- Support cloud Firmware upgrade
- NDAA Compliant
- 32-channel input
- Support 2-ch HDMI, 1-ch VGA independent outputs
- HDMI1 and HDMI2 up to 4K (3840x2160) resolution
- Up to 4K resolution recording
- Support RAID 0, 1,5, 6, 10
- 8 SATA HDDs, up to 10TB for each HDD
- Support N+1 Hot spare
- ANR technology to enhance the storage reliability when the network is disconnected
- Support mainstream camera of ONVIF conformance (Profile G, S, T) and RTSP protocols
- IP Video Input: 32-ch
- Supported camera: advidia M-series
- Audio Input: 1-ch, RCA
- Incoming Bandwidth: 384Mbps
- Outgoing Bandwidth: 384Mbps
- Remote Users: 128
- Protocols: TCP/IP, P2P, UPnP, NTP, DHCP, PPPoE, HTTP, HTTPS, DNS, DDNS, SNMP, SMTP, NFS
- HDMI/VGA Output" HDMI 1/ HDMI 2 (HDMI audio output is not supported)
- 4K (3840x2160)/30Hz, 1920X1080/60Hz, 1920X1080/50Hz, 1600X1200/60Hz, 1280X1024/60Hz, 1280X720/60Hz, 1024X768/60Hz
- VGA: 1920X1080/60Hz, 1920X1080/50Hz, 1280X1024/60Hz, 1280X720/60Hz, 1024X768/60Hz
- Recording Resolution: 12MP/8MP/6MP/5MP/4MP/3MP/1080p/960p/720p/D1/2CIF/CIF
- Recording Mode: Normal, Event, Manual
- Audio Output: 1-ch, RCA
- Camera Control: Pan/Tilt, Zoom, Focus, Iris, Preset Position, Preset Patrol, Recorded Patrol, Auto Guard
- Synchronous Playback: 16-ch
- Multiscreen Mode: Normal Mode: 4/6/8/9/16/25/36
- Corridor Mode: 3/4/5/7/9/10/12/16/32
- Web Client: 4/6/8/9/10/13/16
- Decoding format H.265/H.264
- Live view/Playback: 12MP/8MP/6MP/5MP/4MP/3MP/1080p/960p/720p/D1/2CIF/CIF
- Capability: 2 x12MP@30fps, 4 x 4K@30fps, 8x 4MP@30fps, 9 x 4MP@30fps, 16 x 1080P@30fps, 32 x 720P@30fps
- SATA: 8 SATA interface
- Capacity: Up to 10TB for each disk
- eSATA: 1 eSATA interface.
