Kingston RAM 16GB 3200MT/s DDR4 Non-ECC (KVR32N22S8/16)
$155.00
- Part Number: KVR32N22S8/16
- 16GB 1Rx8 2G x 64-Bit PC4-3200
- CL22 288-Pin DIMM
- CL(IDD): 22 cycles
- Warranty: 3 years on part.
Contact for Price & Stock
Delivery 25 Provinces
Official Warranty
100% Genuine Product
Tech Support
Specifications
- Part Number: KVR32N22S8/16
- SPECIFICATIONS
- 16GB 1Rx8 2G x 64-Bit PC4-3200
- CL22 288-Pin DIMM
- CL(IDD): 22 cycles
- Row Cycle Time (tRCmin): 45.75ns(min.)
- Refresh to Active/Refresh Command Time (tRFCmin): 350ns(min.)
- Row Active Time (tRASmin): 32ns(min.)
- UL Rating: 94 V - 0
- Operating Temperature: 0o C to +85o C
- Storage Temperature: -55o C to +100o C
- FEATURES
- Power Supply: VDD = 1.2V Typical
- VDDQ = 1.2V Typical
- VPP = 2.5V Typical
- VDDSPD = 2.2V to 3.6V
- Nominal and dynamic on-die termination (ODT) for data, strobe, and mask signals
- Low-power auto self refresh (LPASR)
- Data bus inversion (DBI) for data bus
- On-die VREFDQ generation and calibration
- Single-rank
- On-board I2 serial presence-detect (SPD) EEPROM
- 8 internal banks; 2 groups of 4 banks each
- Fixed burst chop (BC) of 4 and burst length (BL) of 8 via the mode register set (MRS)
- Selectable BC4 or BL8 on-the-fly (OTF)
- Fly-by topology
- Terminated control command and address bus
- PCB: Height 1.23” (31.25mm)
- RoHS Compliant and Halogen-Free
- Warranty: 3 years on part.
