Dahua IPC-HFW1431S1-A-S4 4MP Entry IR Fixed-focal Bullet Network Camera
$55.00
- Part Number: IPC-HFW1431S1-A-S4
- 1/2.7” 2MP/4MP(WDR)/5MP(Metal) progressive CMOS
- H.265& H.264 dual-stream encoding
- DWDR, Day/Night(ICR), 3DNR, AWB, AGC, BLC
- Multiple network monitoring: Web viewer, CMS(DSS/PSS) & DMSS
- Abnormality detection: Motion detection, video tampering, network disconnection, IP conflict, illegal access
- 2.8 mm fixed lens (3.6mm optional)
- Built-in Mic (audio)
- Max IR LEDs Length 30m
- IP67, PoE
- Warranty: 1-year on part.
Contact for Price & Stock
Delivery 25 Provinces
Official Warranty
100% Genuine Product
Tech Support
Specifications
- Part Number: IPC-HFW1431S1-A-S4
- Camera
- Image Sensor: 1/2.7" CMOS
- Max. Resolution: 2688 (H) × 1520 (V)
- ROM: 16 MB
- RAM: 128 MB
- Scanning System: Progressive
- Electronic Shutter Speed: Auto/Manual 1/3 s–1/100,000 s
- Min. Illumination
- 0.03 [email protected] (Color, 30 IRE)
- 0.003 [email protected] (B/W, 30 IRE)
- 0 lux (Illuminator on)
- S/N Ratio: > 56 dB
- Illumination Distance: 30 m (98.43 ft) (IR)
- Illuminator On/Off Control: Auto; manual
- Illuminator Number: 1(IR LED)
- Pan/Tilt/Rotation Range
- - Pan: 0°–360°
- - Tilt: 0°–90°
- - Rotation: 0°–360°
- Lens
- Lens Type: Fixed-focal
- Lens Mount: M12
- Focal Length: 2.8 mm; 3.6 mm
- Max. Aperture: 2.8 mm: F2.0 & 3.6 mm: F2.0
- Field of View:
- 2.8 mm: Horizontal: 104°; Vertical: 58°; Diagonal: 124°
- 3.6 mm: Horizontal: 88°; Vertical: 48°; Diagonal: 103°
- Iris Control: Fixed
- Close Focus Distance: 2.8 mm: 0.7 m (2.30 ft) & 3.6 mm: 1.2 m (3.94 ft)
- DORI Distance:
- Lens: 2.8 mm & 3.6 mm
- Detect: 56.0 m (183.73 ft) & 76.0 m (249.34 ft)
- Observe: 22.4 m (73.49 ft) & 30.4 m (99.74 ft)
- Recognize: 11.2 m (36.75 ft) & 15.2 m (49.87 ft)
- Identify: 5.6 m (18.37 ft) & 7.6 m (24.93 ft)
- Video
- Video Compression: H.265; H.264; H.264H; H.264B; MJPEG (Only supported by the sub stream)
- Smart Codec: Smart H.265+; Smart H.264+
- Video Frame Rate
- Main stream:
- 2688 × 1520 (1 fps–20 fps)
- 2560 × 1440 (1 fps–25/30 fps)
- Sub stream:
- 704 × 576 (1 fps–20/25 fps)
- 704 × 480 (1 fps–20/30 fps)
- *The values above are the max. frame rates of each stream; for multiple streams, the values will be subjected to the total encoding capacity.
- Stream Capability: 2 streams
- Resolution
- 2688 × 1520 (2688 × 1520); 2560 × 1440 (2560 × 1440); 2304 × 1296 (2304 × 1296); 1080p (1920 × 1080); 1.3M (1280 × 960); 720p (1280 × 720); D1 (704 × 576/704 × 480); VGA (640 × 480); CIF (352 × 288/352 ×240)
- Bit Rate Control: CBR/VBR
- Video Bit Rate
- H.264: 32 kbps–6144 kbps
- H.265: 12 kbps–6144 kbps
- Day/Night: Auto (ICR)/Color/B/W
- BLC: Yes
- HLC: Yes
- WDR: 120 dB
- White Balance: Auto; natural; street lamp; outdoor; manual; regional custom
- Gain Control: Auto; manual
- Noise Reduction: 3D NR
- Motion Detection: OFF/ON (4 areas, rectangular)
- Region of Interest (RoI): Yes (4 areas)
- Smart Illumination: Yes
- Image Rotation: 0°/90°/180°/270° (Support 90°/270° with 2688 × 1520 resolution and lower.)
- Mirror: Yes
- Privacy Masking: 4 areas
- Audio
- Built-in MIC: Yes
- Audio Compression: G.711A; G.711Mu; G.726
- Alarm
- Alarm Event: Network disconnection; IP conflict; illegal access; motion detection; video tampering; audio detection; security exception
- Network
- Network Port: RJ-45 (10/100 Base-T)
- SDK and API: Yes
- Cyber Security: Video encryption; configuration encryption; Digest; WSSE; account lockout; security logs; generation and importing of X.509 certification; trusted boot; trusted execution; trusted upgrade
- Network Protocol: IPv4; IPv6; HTTP; TCP; UDP; ARP; RTP; RTSP; SMTP; FTP; DHCP; DNS; DDNS; NTP; Multicast
- Interoperability: ONVIF (Profile S/Profile T); CGI; P2P; Genetec
- User/Host: 6 (Total bandwidth: 36 M)
- Storage: FTP
- Browser: IE
- Chrome: Firefox
- Management Software: Smart PSS; DSS; DMSS
- Mobile Client: iOS; Android
- Certification
- Certifications: CE-LVD: EN 62368-1
- CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU
- FCC: 47 CFR FCC Part 15, Subpart B
- Power
- Power Supply: 12 VDC/PoE (802.3af)
- Power Consumption: Basic: 1.9 W (12 VDC); 2.9 W (PoE)
- Max. (ICR + H.265 + IR intensity): 3.8 W (12 VDC); 5 W (PoE)
- Environment
- Operating Temperature: –40 °C to +60 °C (–40 °F to +140 °F)
- Operating Humidity: ≤ 95%
- Storage Temperature: –40 °C to +60 °C (–40 °F to +140 °F)
- Protection: IP67
- Structure: Casing
- Metal + plastic
- Product Dimensions: 162.6 mm × 70 mm× 70 mm (6.40" × 2.76"× 2.76") (L × W × H)
- Net Weight: 0.22 kg (0.5 lb)
- Gross Weight: 0.34 kg (0.7 lb).
