Hikvision IDS-7208HQHI-M1/E 8-ch 1080P 1U H.265 AcuSense DVR
$95.00
- Part Number: IDS-7208HQHI-M1/E
- Deep learning based human and vehicle targets classification of Motion Detection 2.0
- Deep learning-based perimeter protection
- H.265 Pro+/H.265 Pro/H.265 video compression
- HDTVI/AHD/CVI/CVBS/IP video inputs
- Audio via coaxial cable
- Up to 12-ch IP camera inputs (up to 6 MP)
- Up to 1080p@15 fps encoding capability
- Warranty: 1 Year on part
Contact for Price & Stock
Delivery 25 Provinces
Official Warranty
100% Genuine Product
Tech Support
Specifications
- Motion Detection 2.0
- Human/Vehicle Analysis: Deep learning-based motion detection 2.0 is enabled by default for all analog channels, it can classify human and vehicle, and extremely reduce false alarms caused by objects like leaves and lights; Quick search by object or event type is supported;
- Perimeter Protection
- Human/Vehicle Analysis: Up to 4-ch
- Recording
- Video Compression: H.265 Pro+/H.265 Pro/H.265/H.264+/H.264
- Encoding Resolution: When 1080p Lite mode is not enabled: 4 MP Lite/3 MP/1080p/720p/VGA/WD1/4CIF/CIF; When 1080p Lite mode is enabled: 4 MP Lite/1080p Lite/720p Lite/VGA/WD1/4CIF/CIF
- Frame Rate: Main stream: When 1080p Lite mode is not enabled: For 4 MP stream access: 4 MP Lite@15 fps; 1080p Lite/720p/WD1/4CIF/VGA/CIF@25 fps (P)/30 fps (N) For 3 MP stream access: 3 MP/1080p/720p/VGA/WD1/4CIF/CIF@15 fps For 1080p stream access: 1080p/720p@15 fps; VGA/WD1/4CIF/CIF@25fps (P)/30 fps (N) For 720p stream access: 720p/VGA/WD1/4CIF/CIF@25 fps (P)/30 fps (N) When 1080p Lite mode is enabled: 4 MP Lite@15 fps; 1080p Lite/720p Lite/VGA/WD1/4CIF/CIF@25 fps (P)/30 fps (N) Sub-stream: WD1/4CIF@12 fps; CIF@25 fps (P)/30 fps (N)
- Video Bitrate: 32 Kbps to 6 Mbps
- Dual-Stream: Support
- Stream Type: Video, Video & Audio
- Audio Compression:G.711u
- Audio Bitrate: 64 Kbps
- Video And Audio
- IP Video Input: 2-ch (up to 10-ch): Enhanced IP mode on: 4-ch (up to 12-ch), each up to 4 Mbps Up to 6 MP resolution Support H.265+/H.265/H.264+/H.264 IP cameras
- Analog Video Input: 8-ch: BNC interface (1.0 Vp-p, 75 Ω), supporting coaxitron connection
- HDTVI Input: 4 MP, 3 MP, 1080p25, 1080p30, 720p25, 720p30, 720p50, 720p60
- AHD Input: 4 MP, 1080p25, 1080p30, 720p25, 720p30
- HDCVI Input: 4 MP, 1080p25, 1080p30, 720p25, 720p30
- CVBS Input: Support
- HDMI Output 1-ch, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz
- VGA Output: 1-ch, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz
- Video Output Mode: HDMI/VGA simultaneous output
- Audio Input: 1-ch, RCA (2.0 Vp-p, 1 KΩ) 8-ch via coaxial cable
- Audio Output: 1-ch, RCA (Linear, 1 KΩ)
- Two-Way Audio: 1-ch, RCA (2.0 Vp-p, 1 KΩ) (using the first audio input)
- Synchronous Playback: 8-ch
- Network
- Total Bandwidth: 96 Mbps
- Remote Connection: 64
- Network Protocol: TCP/IP, PPPoE, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, NFS, iSCSI, UPnP™, HTTPS, ONVIF
- Network Interface: 1, RJ45 10/100 Mbps self-adaptive Ethernet interface
- Wi-Fi: Connectable to Wi-Fi network by Wi-Fi dongle through USB interface
- Auxiliary Interface
- SATA: 1 SATA interface
- Capacity: Up to 10 TB capacity for each disk
- Alarm In/Out: N/A
- USB Interface: Real panel: 2 × USB 2.0
- General
- Power Supply: 12 VDC, 1.33 A
- Consumption:≤ 12 W (without HDD)
- Working Temperature: -10 °C to +55 °C (+14 °F to +131 °F)
- Working Humidity:10% to 90%
- Dimension (W × D × H): 265 × 225 × 48 mm (10.4 × 8.9 × 1.9 inch) ≤ 1 kg (without HDD, 2.2 lb.)
