Dahua HAC-HFW1509TMP-IL-A 5MP Smart Dual Illuminators Bullet Camera
$50.00
- Part Number: HAC-HFW1509TMP-IL-A
- Max 25 fps@5MP (16:9 video output).
- 120 dB true WDR, 3D NR.
- Smart Dual Illuminators.
- 40 m illumination distance.
- Super Adapt.
- Built-in MIC.
- 3.6 mm fixed lens (2.8 mm optional).
- CVI/CVBS/AHD/TVI switchable.
- IP67, 12 VDC.
- Warranty: 1-Year on part.
Contact for Price & Stock
Delivery 25 Provinces
Official Warranty
100% Genuine Product
Tech Support
Specifications
- Part Number: HAC-HFW1509TMP-IL-A
- Camera
- Pixel: 5MP
- Image Sensor: 5MP CMOS
- Max. Resolution: 2880 (H) × 1620 (V)
- Scanning System: Progressive
- Electronic Shutter Speed: PAL: 1/3 s–1/100000 s; NTSC: 1/4 s–1/100000 s
- Min. Illumination: 0.001 [email protected] (Color, 30 IRE); 0.0001 [email protected] (B/W, 30 IRE); 0 lux (Illuminator on)
- S/N Ratio: >65dB
- Illumination DistanceL IR: 40 m (131.23 ft); Warm light: 40 m (131.23 ft)
- Illuminator On/Off Control: Auto; manual
- Illuminator Number: 2 (IR light), 2 (Warm light)
- Pan/Tilt/Rotation Range: Pan: 0°–360°, Tilt: 0°–90°, Rotation: 0°–360°
- Lens
- Lens Type: Fixed-focal
- Mount Type: M12
- Focal Length: 2.8 mm; 3.6 mm
- Max. Aperture: F1.0
- Field of View: 2.8 mm: H: 111°; V: 57°; D: 131° & 3.6 mm: H: 89°; V: 47°; D: 104°
- Iris Control: Fixed
- Close Focus Distance: 2.8 mm: 1.5 m (4.92 ft) & 3.6 mm: 2.2 m (7.22 ft)
- DORI distance Lens: 2.8 mm, 3.6 mm
- DORI distance Detect: 66.0 m (216.54 ft), 78.0 m (255.91 ft)
- DORI distance Observe: 26.4 m (86.61 ft), 31.2 m (102.36 ft)
- DORI distance Recognize: 13.2 m (43.31 ft), 15.6 m (51.18 ft)
- DORI distance Identify: 6.6 m (21.65 ft), 7.8 m (25.59 ft)
- Video
- Video Frame Rate
- CVI: PAL: 5M@25 fps; 4M@25 fps; 1080p@25 fps
- NTSC: 5M@25 fps; 4M@30 fps; 1080p@30 fps;
- AHD: PAL: 4M@25 fps; NTSC: 4M@30 fps;
- TVI: PAL: 4M@25 fps; NTSC: 4M@30 fps;
- CVBS: PAL: 960H; NTSC: 960H
- Resolution: 5M (2880 × 1620); 4M (2560 × 1440); 1080p (1920 × 1080); 960H (960 × 576/960 × 480)
- Day/Night: Auto (ICR)/Color/B/W
- BLC: BLC; HLC; WDR; HLC-Pro
- WDR: 120dB
- White Balance: Auto; Area white balance
- Gain Control: Auto; manual
- Noise Reduction: 3D NR
- Defog: Electronic defog
- Digital Zoom: 4×
- Mirror: Yes
- Privacy Masking: Off/On (8 areas, rectangle)
- Illumination Mode: Smart IR&WL; WL Mode; IR Mode
- Certifications
- Certifications: CE (EN55032:2015, EN61000-3-2:2014, EN61000-3-3:2013, EN55024:2010+A1:2015, EN55035:2017, EN50130-4:2011+A1:2014, EN62368-1:2014+A11:2017)
- FCC (CFR 47 FCC Part 15 subpartB, ANSI C63.4-2014)
- UL (UL62368-1+CAN/CSA C22.2 No.62368-1-14)
- Port
- Video Output: Video output choices of CVI/TVI/AHD/CVBS by one BNC port
- Audio Input: One channel built-in MIC
- Power
- Power Supply: 12V ± 30% DC
- Power Consumption: Max 5.7 W (12 VDC, LED on)
- Environment
- Operating Temperature: –40 °C to +60 °C (–40 °F to 140 °F)
- Operating Humidity: <95% (RH), non-condensing
- Storage Temperature: –40 °C to +60 °C (-40 °F to 140 °F)
- Protection: IP67
- Structure
- Casing Material: Metal
- Product Dimensions: 240.7 mm × 90.7 mm × 90.7 mm (9.48" × 3.57" × 3.57")
- Packaging Dimensions: 299 mm × 119mm × 111 mm (11.77" × 4.69" × 4.37")
- Net Weight: 0.7 kg (1.54 lb)
- Gross Weight: 0.89 kg (1.96 lb)
- Installation: Wall mount; ceiling mount; vertical pole mount
