Edgecore ECW5211-L Indoor Wi-Fi 5 (802.11ac) Access Point
$245.00
- Part Number: AECW5211-L
- Layer 2 / Layer 3 Fast Roaming
- DSCP (802.1p)
- Up to 867 Mbps (5GHz)
- VLAN Tagging (802.1Q)
- Power / 2.4G-WiFi / 5G-WiFi / Eth1 / Eth2
- Multicast to Unicast Conversion
- 14.7cm x 14.7cm x 3.5cm (W x D x H)
- Band Steering.
- Warranty: 1-Year on part.
Contact for Price & Stock
Delivery 25 Provinces
Official Warranty
100% Genuine Product
Tech Support
Specifications
- Part Number: ECW5211-L
- Channelization: 20 MHz, 40 MHz, 80 MHz
- Frequency Band: 2.412- 2.472 GHz, 5.180- 5.825GHz
- RF Output Power*1: 2.4GHz Up to 21 dBm*2; 5GHz Up to 20 dBm*2 (*1 RF output power aggregates across MIMO chains and doesn't contain antenna gain; *2 Maximum power is limited by local regulatory requirements)
- Radio Chains: 2x2:2
- Mounting: Wall/Ceiling mount (Mounting kit included)
- USB: 1x USB 2.0 Port
- Type: 3 x Built-in PIFA (2x 2.4GHz, 5GHz, 1x Bluetooth Low Energy)
- LAN: 1x 10/100/1000Base-T Ethernet, Auto MDIX, RJ-45
- PoE: 802.3af compliant (PoE injector optional)
- DC Input: 12V / 1.0A
- Deployment: Standalone, Tunneled management by Edgecore EWS Gateway-Controller, IPv4 & IPv6 compatible, LLDP
- Configuration: Web User Interface (HTTP / HTTPS), SNMP v1, v2c, v3
- Uplink: 1x 10/100/1000Base-T Ethernet, Auto MDIX, RJ-45 with 802.3af PoE
- Gain: 3 dBi (2.4GHz), 5 dBi (5GHz), 3 dBi (BLE)
- Operating Temperature: 0°C (32°F) to 50°C (122°F)
- Weight: 0.36 g (0.78 lbs).
