Hikvision DS-K1T805MBWX Access Control Terminal
$85.00
- Part Number: DS-K1T805MBWX
- High protective level: IP65 and IK08
- Slim and flexible design with metal
- 10,000 cards and 100,000 events storage
- Built-in card reader for M1 card
- Supports operation by mobile App (Hik-Connect)
- Supports AP configuration, configuration via PC web and mobile web are available
- Supports multiple authentication types: card, PIN, and bluetooth
- Warranty: 1-year on part.
Contact for Price & Stock
Delivery 25 Provinces
Official Warranty
100% Genuine Product
Tech Support
Specifications
- System
- Operating system: Linux
- Audio
- Audio output: 1 built-in buzzer
- Network
- Bluetooth: Support
- Wired network: 10/100 Mbps self-adaptive
- Wi-Fi: 2.4 GHz, IEEE802.11b, 802.11g, 802.11n, 802.11d, 802.11e, 802.11h, 802.11i
- Interface
- RS-485: 1, supports OSDP
- Network interface: 1
- Wiegand: Wiegand 26/34
- Lock control: 1
- Exit button: 1
- Door contact input: 1
- Alarm input: 2
- Alarm output: 1
- TAMPER: 1
- Capacity
- Card capacity: 10,000
- Event capacity: 100,000
- Authentication
- Card type: M1 card
- Card reading distance: 0 to 4 cm
- Card reading duration: ＜ 1 s
- General
- Power supply: 12 VDC/1 A
- Working temperature: -30 °C to 60 °C (-22 °F to 140 °F)
- Working humidity: 0% to 90% (no condensing)
- Dimensions: 57.7 mm × 177 mm × 34.6 mm (2.3" × 7.0" × 1.4")
- Power consumption: ≤ 12 W
- Language: English, Vietnamese, Brazilian Portuguese, Spanish, French, Italian, Arabic, Thai, Turkish, Indonesian, Ukrainian, and Russian
- Function
- Hik-Connect: Support
- Configuration via Web Browser
- Support PC web configuration and mobile web operation.
