Hikvision DS-3E0526P-E/M 24Port Gigabit Unmanaged POE Switch
$165.00
- Part Number: DS-3E0526P-E/M
- 24 Port Gigabit Unmanaged POE Switch
- L2, Unmanaged, 24 Gigabit POE ports, 2 Gigabit SFP uplink ports
- 802.3af/at, PoE power budget 225w
- IEEE 802.3, IEEE 802.3u, and IEEE 802.3x standard
- 6 KV surge protection for PoE ports
- Warranty: 1 Year on part
Contact for Price & Stock
Delivery 25 Provinces
Official Warranty
100% Genuine Product
Tech Support
Specifications
- Network Parameters
- Ports: 24 × Gigabit PoE ports, and 2 × Gigabit fiber optical ports
- Port Type: RJ45 port, full duplex, MDI/MDI-X adaptive
- Standard: IEEE 802.3, IEEE 802.3u, IEEE 802.3x, IEEE 802.3ab, IEEE 802.3z
- Forwarding Mode: Store-and-forward switching
- MAC Address Table: 8 K
- Switching Capacity: 52 Gbps
- Packet Forwarding Rate: 38.688 Mpps
- Internal Cache: 4.1 Mbits
- PoE Power Supply
- PoE Standard: IEEE 802.3af, IEEE 802.3at
- PoE Power Pin: End-span: 1/2(-), 3/6(+)
- PoE Port: Ports 1 to 24
- Max. Port Power: 30 W
- PoE Power Budget: 225 W
- General
- Dimensions (W × H × D): 440 mm × 44 mm × 220.8 mm (17.3” × 1.7” × 8.7”)
