Hikvision DS-3E0116R-O 16-Port Fast Ethernet Switch
$39.00
- Part Number: DS-3E0116R-O
- 16-Port Fast Ethernet Switch
- 16 × 10/100 Mbps RJ45 Port
- Easy Plug-and-Play Installation
- Desk or rack installation and wall-mounting
- Rugged Metal Case
- Warranty: 1 Year on part.
Contact for Price & Stock
Delivery 25 Provinces
Official Warranty
100% Genuine Product
Tech Support
Specifications
- General
- Shell: Metal material, fan-free design
- Net Weight: 1.1 kg (2.42 lb)
- Gross Weight: 1.5 kg (3.3 lb)
- Dimensions (W × H × D): 257..0 mm × 44.5 mm × 175.8 mm (10.118'' × 1.751'' × 6.921'')
- Operating Temperature: 0 °C to 40 °C (32 °F to 104 °F)
- Storage Temperature: -40 °C to 85 °C (-40 °F to 185 °F)
- Operating Humidity: 5% to 95% (no condensation)
- Relative Humidity: 5% to 95% (no condensation)
- Power Supply: 220 VAC, 50/60 Hz
- Max. Power Consumption: 6.6 W
- Power Consumption in Idle: <6.6 W
- Surge Protection: 6 KV
- Network Parameters
- Ports: 16 × 10/100 Mbps RJ45 port
- MAC Address Table: 8 K
- Switching Capacity: 3.2 Gbps
- Packet Forwarding Rate: 2.38 Mpps
- Internal Cache: 2 Mbits
- Approval
- EMC: FCC (47 CFR Part 15, Subpart B),CE-EMC (EN 55032: 2015+A11: 2020, EN IEC 61000-3-2: 2019, EN 61000-3-3: 2013+A1: 2019, EN 50130-4: 2011+A1: 2014, EN 55035: 2017+A11: 2020),IC (ICES-003: Issue 7:2020)
- Safety: UL (UL 60950-1),CB (AMD1:2009, AMD2:2013, IEC 62368-1: 2014 (Second Edition), CE-LVD (EN 62368-1: 2014+A11: 2017)
- Chemistry: CE-RoHS (2011/65/EU),WEEE (2012/19/EU),Reach (Regulation (EC) No.1907/2006)
- Warranty: 1 Year on part.
