Hikvision DS-3E0105P-E/M(B) 4Port Fast Ethernet Unmanaged POE Switch
$38.00
- Part Number: DS-3E0105P-E/M(B)
- Intelligent PoE Management. When the power supply exceeds the limit, PoE ports intelligently manage the power supply, which extends the switch lifetime.
- Up to 300 m Long Range PoE Transmission. The distance between IPCs and switch can reach maximum 300 meters.
- 4/8-Core Adaptive Power Supply with Less Power Loss. 8-core power supply reduces the power loss on cables.
- 6KV Surge Protection to Improve Reliability in Harsh Environment. The built-in surge protection device protects the switch from the sudden lightning surge in harsh environment.
- Design for Video Transmission. VIP port ensures important data transmission when network congestion occurs.
- Warranty: 1 Year on part
Contact for Price & Stock
Delivery 25 Provinces
Official Warranty
100% Genuine Product
Tech Support
Specifications
- PoE Power Supply
- PoE Standard: IEEE 802.3af, IEEE 802.3at
- PoE Power Pin: Supports 8-core power supply, Ethernet cable 1/2/3/6 and 4/5/7/8 provide simultaneous power supply
- PoE Port: Ports 1 to 4
- Max. Port Power: 30 W
- PoE Power Pudget: 35 W
- Max. Power Consumption: 38 W
- Network Parameters
- Port Number: 4 × 100 Mbps PoE ports, 1 × 100 Mbps Ethernet port
- Port Type: RJ45 port, full duplex, MDI/MDI-X adaptive
- Standard: IEEE 802.3, IEEE 802.3u, IEEE 802.3x
- Forwarding Mode: Store-and-forward switching
- Working Mode: Standard mode (default); Extend mode
- High Priority Ports: Ports 1 to 2
- Ports For Long-Distance Transmission: Ports 1 to 4
- MAC Address Table: 1 K
- Switching Capacity: 1 Gbps
- Packet Forwarding Rate: 0.744 Mpps
- Internal Cache: 448 Kbits
- General
- Dimension (L × H × D): 105 mm × 27.6 mm × 83.1 mm (4.1” × 1.1” × 3.3”)
