Dahua DH-HAC-HFW1200DP 2MP HDCVI IR Bullet Camera
$29.00
- Part Number: DH-HAC-HFW1200DP
- The parameters and datasheets below can only be applied to 1200-S5 series
- Max 30fps@1080P- CVI/CVBS/AHD/TVI switchable
- 3.6mm fixed lens (6mm, 8mm optional)
- Max. IR length 80m, Smart IR
- IP67, DC12V
- Camera Dimensions 241.8 mm × 90.4 mm × 90.4 mm ( 9.52" × 3.56" × 3.56" )
- Warranty: 1Year on part
Contact for Price & Stock
Delivery 25 Provinces
Official Warranty
100% Genuine Product
Tech Support
Specifications
- Part Number: DH-HAC-HFW1200DP
- Camera
- Image Sensor: 1/2.7" CMOS
- Effective Pixels: 1920(H)×1080(V), 2MP
- Scanning System: Progressive
- Electronic Shutter Speed: PAL: 1/25~1/100000s, NTSC: 1/30~1/100000s
- Minimum Illumination: 0.02Lux/F2.0, 30IRE , 0Lux IR on
- S/N Ratio: More than 65dB
- IR Distance: Up to 80m (262feet)
- IR On/Off Control: Auto / Manual
- IR LEDs: 2
- Lens
- Lens Type: Fixed lens / Fixed iris
- Mount Type: Board-in
- Focal Length: 3.6mm (6mm, 8mm Optional)
- Max Aperture: F2.0
- Angle of View: H: 89.9°(54.7°/41.6°)
- Focus Control: N/A
- Close Focus Distance: 900mm(2000mm/2800mm), 35.4'' (78.7''/110.2'')
- DORI Distance
- DORI Definition Distance
- Detect: 25px/m (8px/ft), 3.6mm: 53m(175ft), 6mm: 80m(262ft), 8mm: 104m(341ft)
- Observe: 63px/m (19px/ft), 3.6mm: 21m(70ft), 6mm: 32m(105ft), 8mm:42m(136ft)
- Recognize: 125px/m (38px/ft), 3.6mm: 11m(35ft), 6mm: 16m(52ft), 8mm:21m(68ft)
- Identify: 250ppm (76px/ft), 3.6mm: 5m(17ft), 6mm: 8m(26ft), 8mm: 10m(34ft)
- Pan / Tilt / Rotation
- Pan/Tilt/Rotation Pan: 0° ~ 360°, Tilt: 0° ~ 87°, Rotation: 0° ~ 360°
- Video
- Resolution: 1080P (1920×1080)
- Frame Rate: 25/30fps@1080P, 25/30/50/60fps@720P
- Video Output: 1-channel BNC high definition video output / CVBS video output (Can switch)
- Day/Night: Auto (ICR) / Manual
- OSD Menu: Multi-language
- BLC Mode: BLC / HLC / DWDR
- WDR DWDR Gain Control: AGC
- Noise Reduction: 2D
- White Balance: Auto / Manual
- Smart IR: Auto / Manual
- Construction
- Casing: Aluminium
- Dimensions: 241.8mm×90.4mm×90.4mm (9.52"×3.56"×3.56")
- Net Weight: 0.62kg (1.36lb)
- Gross Weight: 0.73kg (1.61lb)
