Dahua CS4006-4ET2GT-36 6-Port Cloud Managed Desktop Switch with 4-Port PoE
$32.00
- Part Number: CS4228-24GT-240
- 4 RJ-45 10/100 Mbps PoE ports
- 2 x RJ-45 Gigabit ports
- 36 W total PoE budget
- 802.3af/at on all PoE ports
- Manages PoE power consumption and PoE power on/off. Supports Intelligent PoE.
- A wide operating temperature range and a full metal casing that is fully-enclosed and dust-proof
- Warranty:1-year on part.
Contact for Price & Stock
Delivery 25 Provinces
Official Warranty
100% Genuine Product
Tech Support
Specifications
- Part Number: DH-CS4228-24GT-240
- Basic
- Layer: Layer 2
- Switching Capacity: 4.8 Gbps
- Packet Forwarding Rate: 3.57 Mpps
- Description of Function Slots: Port 1-4: 4 RJ-45 10/100 Mbps (PoE); Port 5-6: 2 RJ-45 10/100/1000 Mbps (uplink)
- Operating Temperature: 10 C to +55 C (+14 F to +131 F)
- Operating Humidity: 10%90% (RH), non-condensing
- Storage Temperature: 40 C to +70 C (40 F to +158 F)
- Storage Humidity: 5%95% (RH), non-condensing
- Power Supply: External power supply: 53 VDC, 0.8 A
- Power Consumption: Idling: 3 W; Full load: 42.4 W
- Statics Protection: Air discharge: 8 kV; Contact discharge: 6 kV
- Lightning Protection: Common mode: 6 kV; Differential mode: 0 kV
- Net Weight: 0.2 kg (0.44 lb)
- Gross Weight: 0.72 kg (1.59 lb)
- Product Dimensions: 115 mm 84 mm 27 mm (4.53" 3.33" 1.06") (L W H)
- Packaging Dimensions: 195 mm 114 mm 83 mm (7.68" 4.49" 3.27") (L W H)
- Casing Material: Sheet metal
- Installation: Desktop mount; wall mount
- Certifications: CE
- PoE
- PoE: Yes
- PoE Power: Port 1-4 30 W, total 36 W
- PoE Protocol: IEEE802.3af; IEEE802.3at
- PoE Power Consumption Management: PoE power consumption management; PoE power on/off; turns off PoE if overload is detected
- PoE Pin Assignment: 1, 2, 4, 5V+, 3, 6, 7, 8V-
- Long Distance PoE Transmission: Yes.
- Hardware
- DIP Switch: Managed Mode: On by default for both local web and cloud management. Off for Unmanaged Mode.
- PoE Watchdog: Monitors ports 1-4 and auto-restarts the PoE port when there is no traffic for 2 min. (Only works when Managed Mode is Off)
- Extend Mode: Ports 1-4; transmission distance up to 250 meters at 10 Mbps. (Only works when Managed Mode is Off)
- Reset Button: 1
- Performance
- MTBF: 232.62 years
- Packet Buffer Size: 4 Mbit
- Jumbo Frame: 9216 Byte
- MAC Table Size: 2K
- Communication Standard: IEEE 802.3; IEEE 802.3u; IEEE 802.3x; IEEE 802.3ab; IEEE 802.3az
- VLAN Number: 32
- Feature
- VLAN Function: IEEE 802.1Q VLAN
- Port Feature: IEEE 802.3x Flow Control; Unknown Unicast Suppression; Multicast Storm Control; Broadcast Storm Control; MAC+Port Binding Loop; Prevention
- Mirror: N:1 Mirroring; Local Port Mirroring
- Reliability: LLDP
- DHCP Function: DHCP Client
- Security: Port Isolation
- Equipment Management: Web Management; Cloud Management; Logs; Fault Alarm
- General
- Packing List: Quick Start Guide 1; Legal and Regulatory Information 1; Power adapter 1; Power cord 1
