D-Link DGS-3130-54PS 54-Port L3 Fully Managed Gigabit PoE Switch
$1,439.00
- Part Number: DGS-3130-54PS
- 24 or 48 10/100/1000BASE-T PoE or non-PoE ports
- 24 or 48 SFP ports
- 2 10GBASE-T and 4 10G SFP+ embedded uplink ports
- Redundant power supply (RPS) support
- Ethernet Ring Protection Switching (ERPS) for
- single ring topologies
- Embedded 6 kV surge protection on all Gigabit
- IEEE 802.3D/802.1s Spanning Tree
- Loopback Detection (LBD)
- Warranty: 3 Years on part.
Contact for Price & Stock
Delivery 25 Provinces
Official Warranty
100% Genuine Product
Tech Support
Specifications
- Part Number: DGS-3130-54PS
- Interfaces Ports
- - 48 x 10/100/1000BASE-T PoE ports
- - 2 x 10GBASE-T ports
- - 4 x 10G SFP+ ports
- Optional Redundant Power Supply: DPS-700
- Console Port: 10/100/1000BASE-T RJ-45 port for out-of-band CLI management
- Management Port: 10/100/1000BASE-T RJ-45 port for out-of-band IP management
- USB Ports: 1 x USB 2.0 Type A port
- Switching Capacity: 216 Gbps
- 64-Byte Packet Forwarding Rate: 161 Mbps
- Packet Buffer Memory: 4 MB
- PoE Standards: IEEE 802.3af & IEEE 802.3at
- PoE Power Budget: 370 W, 740 W (with DPS-700 RPS)
- Physical MTBF (Hours): 356,876 hours
- Acoustics: Max: 54.2 dB, Min: 36.8 dB
- Heat Dissipation: 1662.6 BTU/h (with 370 W PoE load), 3097.24 BTU/h (with 740 W PoE load)
- Power Input: 100 to 240 VAC, 50 to 60 Hz
- Max Power Consumption
- - 487.26 W (with 370 W PoE load)
- - 907.71 W (with 740 W PoE load)
- Dimensions (W xD x H): 440 x 350 x 44 mm (17.32 x 13.78 x 1.73 in)
- Weight: 5.14 g (11.33 lbs)
