D-Link DES-1016D 16-Port Fast Ethernet Unmanaged Switch
$39.00
- Part Number: DES-1016D
- Brand Name: D-Link
- Warranty: 3 Years on part
Contact for Price & Stock
Delivery 25 Provinces
Official Warranty
100% Genuine Product
Tech Support
Specifications
MAC Address Learning:
- Automatic update
Packet Filtering/Forwarding Rates (half duplex):
- Ethernet: 14,880 pps per port
- Fast Ethernet: 148,800 pps per port
RAM Buffer:
- DES-1016D: 256 Bytes (2M bits)
- DES-1024D: 256 Bytes (2M bits)
POWER Input:
- 100~240 V AC 50/60 Hz internal universal power supply
MTBF:
- DES-1016D: 2,266,559 hours
- DES-1024D: 2,058,943 hours
Dimensions (W x D x H):
- 280 x 125.8 x 44 mm (11.0 x 5.0 x 1.7 inches)
Certifications:
- FCC Class A
- ICES-003 Class A
- CE Class A
- C-Tick Class A
- VCCI Class A
- cUL
- LVD
Key Features:
- Inexpensive Fast Ethernet solution for SOHO/SMB
- Auto MDI/MDIX crossover for all ports
- Store-and-forward switching scheme
- Full/half-duplex for Ethernet/Fast Ethernet speeds
- IEEE 802.3x Flow Control
- Plug-and-play installation
Switching fabric:
- DES-1016D: 3.2 Gbps switching fabric
- DES-1024D: 4.8 Gbpsswitching fabric
Standards:
- IEEE 802.3 10BASE-T Ethernet (twistedpair copper)
- IEEE 802.3u 100BASE-TX Fast Ethernet (twisted-pair copper)
- ANSI/IEEE 802.3 NWay Auto-Negotiation
- IEEE 802.3x Flow Control
- IEEE 802.3az EEE function
Protocol:
- CSMA/CD
Data Transfer Rates:
Ethernet:
- 10 Mbps (half duplex)
- 20 Mbps (full duplex)
- Fast Ethernet:
- 100 Mbps (half duplex)
- 200 Mbps (full duplex)
Number of Ports:
- DES-1016D: 16 10/100Mbps Fast Ethernet ports
- DES-1024D: 24 10/100Mbps Fast Ethernet ports
Network Cables:
10BASE-T:
- UTP CAT 3/4/5/5e (100 m max.)
- EIA/TIA-586 100-ohm STP (100 m max.)
- 100BASE-TX UTP CAT 5/5e (100 m max.)
- EIA/TIA-568 100-ohm STP (100 m max.)
Media Interface Exchange:
- Auto MDI/MDIX adjustment for all ports
LED Indicators:
- Per port: Link/Activity
- Per device: Power
Transmission Method:
- Store-and-forward.
