Cisco CBW140AC-S 802.11ac 2x2 Wave 2 Ceiling Mount Access Point
$199.00
- Part Number: CBW140AC-S
- Maximum # of Access Points: 50
- Recommended up to 25
- 2.4 GHz, gain 2 dBi
- 5 GHz, gain 4 dBi
- Warranty: Life time warranty.
Contact for Price & Stock
Delivery 25 Provinces
Official Warranty
100% Genuine Product
Tech Support
Specifications
- Part Number: CBW140AC-S
- Specification
- Authentication and security:
- Wi-Fi Protected Access 2 (WPA2) WPA3 is coming in a post–Frame Check Sequence (FCS) release
- 802.1X, RADIUS Authentication, Authorization, and Accounting (AAA)
- Segmentation via VLANs (up to 16)
- 802.11r and 802.11i
- Guest network can also authenticate against: Google and Facebook
- Maximum clients: Maximum number of associated wireless clients: 200 per Wi-Fi radio, for a total of 400 clients per access point, or 1000 in a system
- Maximum # of Access Points: 50
- Recommended up to 25
- Max # of Mesh Extenders:
- Maximum number of associated Cisco Business mesh extenders: 25 per Access Point, up to 8 hops
- 802.11ac:
- 2x2 single-user/multi-user MIMO with two spatial streams, up to 867 Mbps in 5GHz
- 20-, 40-, and 80-MHz channels
- Dynamic Frequency Selection (DFS)
- Ethernet ports:
- Authentication with 802.1X or MAC filtered
- Dynamic VLAN or per port
- Traffic locally switched or tunneled back to Master AP
- Integrated antennas:
- 2.4 GHz, gain 2 dBi
- 5 GHz, gain 4 dBi
- Interfaces:
- 1x Gigabit Ethernet (10/100/1000BASE-T autosensing), Power over Ethernet (PoE)
- RJ-45 console port (not functional)
- Indicators: Status LED indicates boot loader status, association status, operating status, boot loader warnings, boot loader errors
- Dimensions (W x L x H) : 6 x 6 x 1.3 in. (150.8 x 150.8 x 33 mm)
- Weight: 14 oz (400 g)
- Environmental
- Operating
- Temperature: 32° to 104°F (0° to 50°C)
- Humidity: 10% to 90% (noncondensing)
- Maximum altitude: 9843 ft (3000 m) at 40°C
- Nonoperating (storage and transportation)
- Temperature: –22° to 158°F (-30° to 70°C)
- Humidity: 10% to 90% (noncondensing)
- Maximum altitude: 15,000 ft (4500 m) at 25°C
- System:
- 1 GB DRAM, 256 MB flash
- 710-MHz quad core processor
- Powering options:
- 802.3af/at Ethernet switch; a Cisco Business switch with PoE is recommended
- Optional Cisco Business PoE injector
- Power draw: 8.3W (maximum, on PoE)
- Mounting and physical security Included with the access point:
- Mounting bracket
- Torx security screw
- Ceiling rail mount clip
