EZVIZ TY7 Dual 2K⁺ Dual-Lens Pan & Tilt Wi-Fi Camera
$59.00
- Part Number: CS-TY7 (4MP)
- Dual 2K+ Resolution (2560 × 1440)
- 1/3" Progressive Scan CMOS
- Self-adaptive shutter
- [email protected] Lens
- IR-cut filter with auto-switching
- Warranty: 1-year on part.
Contact for Price & Stock
Delivery 25 Provinces
Official Warranty
100% Genuine Product
Tech Support
Specifications
- Part Number: CS-TY7 (4MP)
- Model: CS-TY7-R100-8G44WF
- Camera
- Resolution: Dual 2K+ Resolution
- Image Sensor: 1/3" Progressive Scan CMOS
- Shutter Speed: Self-adaptive shutter
- Wide-angle Lens: [email protected] , view angle: 108°(Diagonal), 92° (Horizontal), 50°(Vertical)
- PT Lens: [email protected] , view angle: 60°(Diagonal), 51° (Horizontal), 28°(Vertical)
- Lens Mount: M12
- Day & Night: IR-cut filter with auto-switching
- DNR: 3D DNR
- WDR: Digital WDR
- Compression
- Video Compression: H.264/H.265
- Video Bit Rate: Adaptive bit rate.
- Network
- Smart Alarm: Motion Detection, Human Shape Detection, Loud Noise Detection, Patrol Mode Detection
- Wi-Fi Pairing: AP paring
- Protocol: EZVIZ cloud proprietary protocol
- Interface Protocol: EZVIZ cloud proprietary protocol
- Image
- Max. Resolution: 2560 × 1440
- Frame Rate: Self-Adaptive during network transmission
- Interface
- Storage: Micro SD card slot (Max. 512G)
- Power: TYPE-C
- Wired Network: RJ45 X 1 (10M/100M self-adaptive Ethernet port)
- Wi-Fi
- Standard: IEEE802.11a, IEEE802.11b, 802.11g, 802.11n,802.11ac 802.11ax
- Frequency Range: 2.4GHz: 2.4 GHz ~ 2.4835 GHz 5GHz: 5.15GHz~5.25GHz
- Channel Bandwidth: 2.4GHz Supports 20MHz 5GHz Supports 80MHz
- Security: WPA-PSK, WPA2-PSK, WPA3-Personal
- Transmission Rate: 2.4GHz Max. Rate Support: 11b_11M，11g_54M, 11n_MCS7_20M，11ax_MCS11_20M 5.15-5.25GHz Max. Rate Support: 11a_54M, 11n_MCS7_20-40M，11ac_MCS9_20-40-80M, 11ax_MCS11_20-40-80M
- Output Power(EIRP): 20 dBm
- Antenna Gain: [email protected]，[email protected]
- General
- Operating Conditions: -10°C to 45°C ( -14 °F to 113 °F ) Humidity 95% or less (non-condensing)
- Power Consumption: 8W max
- Power Supply: DC 5V/2A
- IR Range: MAX. 10 meters (32.81ft)
- Dimensions: 88 × 88 × 131.5 mm (3.46 × 3.47 ×4.69 in)
- Package Dimensions: 105 × 105 × 200 mm (4.13 × 4.13 × 7.87 in)
- Net Weight: 270 g
- Bare Weight: 530 g
- In the box
- In the box
- - Camera
- - Power Adapter
- - Power Cable
- - Drill Template
- - Mounting Plate
- - Screw Kit
- - Regulatory Information
- - Quick Start Guide
- Certifications
- Certifications: CE / WEEE / RoHS / REACH / UL
