APC Easy UPS 700VA, 230V, AVR, Nema Universal Sockets (BVG700I-MSN)
$75.00
- Part Number: BVG700I-MSN
- Main Input Voltage: 220...240 V AC 1 phase
- Input Connection: Type NEMA 3.2 A
- Output voltage: 230 V AC 1 phase
- Rated power in W: 360 W
- Rated power in VA: 700 VA
- Output connection type: 4
- Output connector type: Universal
- Maximum configurable power in W : 255 W
- UPS type: Line interactive
- Warranty: 2 years on repair or replace.
Contact for Price & Stock
Delivery 25 Provinces
Official Warranty
100% Genuine Product
Tech Support
Specifications
- Part Number: BVG700I-MSN
- Overview
- Lead time: Usually in Stock
- Main
- Run time for load: 360 W
- Min-max: 10-360 W: —
- Max. Capacity Used: 100 %
- Main Input Voltage: 220...240 V AC 1 phase
- Input Connection Type: NEMA 3.2 A
- Input protection type: Circuit breaker
- Network frequency: 50/60 Hz +/- 5 Hz indoor use only
- Output voltage: 230 V AC 1 phase
- Rated power in W: 360 W
- rated power in VA: 700 VA
- Output connection type: 4
- Output connector type: Universal
- Maximum configurable power in W: 255 W
- Output voltage tolerance: +/- 10 %
- Transfer time: 6 ms typical : 10 ms maximum
- UPS type: Line interactive
- Wave type: Stepped approximation to a sinewave
- Full load runtime: 00:00:01 360 W
- Half load runtime: 00:05:00 180 W
- Complementary
- Battery type: VRLA
- Extended runtime: 0
- Number of battery replacement quantity: 0
- Battery charger power: 14 W indoor use only
- Battery type: Lead-acid internal included
- Control panel: LED Status display with on line : on battery
- Emergency power off: No
- Alarm: Alarm when on battery : distinctive low battery alarm : high temperature : overload continuous tone alarm
- Surge energy rate: 156 J
- Colour: Black
- Height: 142 mm
- Width: 101 mm
- Depth: 300 mm
- Net weight: 4.2 kg
- USB compatible: No
- Mounting mode: Desktop installation compact
- Max runtime: 0.01 min
- Range of product: Easy UPS
- Product or component type: Uninterruptible power supply (UPS)
- Environment
- Ambient air temperature for operation: 0…40 °C
- Ambient air temperature for storage: -15…45 °C
- Storage altitude: 0…3000 m
- IP degree of protection: IP20 indoor use only
- Relative humidity: 0…95 % non-condensing
- Storage Relative Humidity: 0…95 % non-condensing
- Acoustic level: < 40 dBA
- Operating altitude: 0...3000 m
- Packing Units
- Unit Type of Package 1: PCE
- Number of Units in Package 1: 1
- Package 1 Height: 14.2 cm
- Package 1 Width: 10.1 cm
- Package 1 Length: 30 cm
- Package 1 Weight: 4.2 kg
- SCC14: 10731304769597
