TP-Link Archer C80 AC1900 Wireless MU-MIMO Wi-Fi Router
$42.00
- Part Number: Archer C80
- 802.11ac Wave2 Wi-Fi – 1300 Mbps on the 5 GHz band and 600 Mbps on the 2.4 GHz band.
- 3×3 MIMO Technology – Transmitting and receiving data on three streams to pair flawlessly with your 3×3 clients.
- Boosted Wi-Fi Coverage – Beamforming technology delivers a highly efficient wireless connection.
- MU-MIMO – To help your devices achieve optimal performance by making communication more efficient.
- Warranty: 3 Years on part.
Contact for Price & Stock
Delivery 25 Provinces
Official Warranty
100% Genuine Product
Tech Support
Specifications
- Part Number: Archer C80
- WIRELESS
- Standards and Protocols: Wi-Fi 5
- - IEEE 802.11ac/n/a 5 GHz
- - IEEE 802.11n/b/g 2.4 GHz
- WiFi Speeds: AC1900
- - 5 GHz: 1300 Mbps (802.11ac)
- - 2.4 GHz: 600 Mbps (802.11n)
- WiFi Range:
- 3 Bedroom Houses
- 4× Fixed High-Performance Antennas
- Multiple antennas form a signal-boosting array to cover more directions and large areas
- Beamforming
- Concentrates wireless signal strength towards clients to expand WiFi range
- WiFi Capacity:
- Medium
- Dual-Band
- Allocate devices to different bands for optimal performance
- 3×3 MU-MIMO
- Simultaneously communicates with multiple MU-MIMO clients
- Airtime Fairness
- Improves network efficiency by limiting excessive occupation
- Working Modes: Router Mode & Access Point Mode
- SECURITY
- Network Security:
- - SPI Firewall
- - Access Control
- - IP & MAC Binding
- - Application Layer Gateway
- Guest Network:
- - 1× 5 GHz Guest Network
- - 1× 2.4 GHz Guest Network
- WiFi Encryption:
- - WPA
- - WPA2
- - WPA3
- - WPA/WPA2-Enterprise (802.1x)
- HARDWARE
- Processor: 1.2 GHz CPU
- Ethernet Ports:
- - 1× Gigabit WAN Port,
- - 4× Gigabit LAN Ports
- Buttons:
- - WPS/Wi-Fi Button
- - Power On/Off Button
- - Reset Button
- Power: US Version 12 V ⎓ 1.5 A
- Power: EU Version: 12 V ⎓ 1 A
- OTHER
- Network Services Enabled by Default:
- - Web Server
- - Manage and configure device through web (HTTP/HTTPS)
- - Port: 80/443 Protocol: TCP
- - DNS
- - DNS
- - Port: 53 Protocol: TCP & UDP
- DHCP Server
- IP address assignment (DHCP)
- - Port: 67 Protocol: UDP
- App management
- Manage and configure device through app
- - Port: 20002 Protocol: UDP
- Alexa service
- Detect Alexa-enabled devices in the LAN
- - Port: 5353 Protocol: UDP
- System Requirements:
- - Internet Explorer 11+, Firefox 12.0+, Chrome 20.0+, Safari 4.0+, or other JavaScript-enabled browser
- - Cable or DSL Modem (if needed)
- - Subscription with an internet service provider (for internet access)
- Certifications: FCC, CE, RoHS
- Environment:
- Operating Temperature: 0℃~40℃ (32℉ ~104℉)
- Storage Temperature: -40℃~70℃ (-40℉ ~158℉)
- Operating Humidity: 10%~90% non-condensing
- Storage Humidity: 5%~90% non-condensing
- TEST DATA
- WiFi Transmission Power
- CE:
- <20dBm(2.4GHz)
- <23dBm(5.15GHz~5.25GHz)
- FCC:
- <30dBm(2.4GHz & 5GHz)
- WiFi Reception Sensitivity 5GHz:
- 11a 6Mbps:-98dBm, 11a 54Mbps:-78dBm
- 11ac VHT20_MCS0:-98dBm, 11ac VHT20_MCS8:-72dBm
- 11ac VHT40_MCS0:-92dBm, 11ac VHT40_MCS9:-68dBm
- 11ac VHT80_MCS0:-89dBm, 11ac VHT80_MCS9:-64dBm
- 2.4GHz:
- 11g 6Mbps:-97dBm, 11a 54Mbps:-77dBm
- 11n VHT20_MCS0:-97dBm, 11n VHT20_MCS8:-72dBm
- 11n VHT40_MCS0:-92dBm, 11n VHT40_MCS9:-67dBm
- PHYSICAL
- Dimensions (W×D×H): 8.5 × 4.6 × 1.26 in (215 × 117 × 32 mm)
- Package Content:
- - Wi-Fi Router Archer C80
- - Power Adapter
- - RJ45 Ethernet Cable
- - Quick Installation Guide
- Warranty: 3-years on part.
