TP-Link Archer C50 AC1200 Wireless Dual Band Router
$25.00
- Part Number: Archer C50
- Support smooth 4K streaming with AC1200 Wi-Fi
- 4 external antennas provide stable wireless connections and optimal coverage
- Easy network management at your fingertips with TP-Link Tether
- Supports IGMP Proxy/Snooping, Bridge and Tag VLAN to optimize IPTV streaming
- Supports Access Point mode to create a new Wi-Fi access point
- Warranty: 3 Years on part
Contact for Price & Stock
Delivery 25 Provinces
Official Warranty
100% Genuine Product
Tech Support
Specifications
- Part Number: Archer C50
- WIRELESS
- Standards and Protocols: Wi-Fi 5
- IEEE 802.11ac/n/a 5 GHz
- IEEE 802.11n/b/g 2.4 GHz
- WiFi Speeds: AC1200
- -5 GHz: 867 Mbps (802.11ac)
- -2.4 GHz: 300 Mbps (802.11n)
- WiFi Range: 3 Bedroom Houses
- 4× Fixed Antennas
- Multiple antennas form a signal-boosting array to cover more directions and large areas
- Beamforming
- Concentrates wireless signal strength towards clients to expand WiFi range
- WiFi Capacity: Medium
- Dual-Band
- Allocate devices to different bands for optimal performance
- 2×2 MU-MIMO
- Simultaneously communicates with multiple MU-MIMO clients
- Working Modes:
- -Router Mode
- -Access Point Mode
- -Range Extender Mode
- SECURITY
- Network Security:
- SPI Firewall
- Access Control
- IP & MAC Binding
- Application Layer Gateway
- Guest Network:
- 1× 5 GHz Guest Network
- 1× 2.4 GHz Guest Network
- WiFi Encryption:
- WPA
- WPA2
- WAP3
- WPA/WPA2-Enterprise (802.1x)
- HARDWARE
- Processor: Single-Core CPU
- Ethernet Ports:
- -1× 10/100 Mbps WAN Port
- -4× 10/100 Mbps LAN Ports
- Buttons:
- WPS/Wi-Fi Button
- Power On/Off Button
- Reset Button
- Power: 9 V ⎓ 0.85 A
- SOFTWARE
- Protocols: IPv4 & IPv6
- Parental Controls: URL Filtering, Time Controls
- WAN Types: Dynamic IP, Static IP, PPPoE, PPTP, L2TP
- Quality of Service: QoS by Device
- NAT Forwarding: Port Forwarding Port Triggering, DMZ, UPnP
- IPTV:
- IGMP Proxy
- IGMP Snooping
- Bridge
- Tag VLAN
- DHCP
- Address Reservation
- DHCP Client List
- Server
- DDNS
- NO-IP
- DynDNS
- Management Features: Tether App
- Webpage: Check Web Emulator>
- OTHER
- System Requirements: Internet Explorer 11+, Firefox 12.0+, Chrome 20.0+, Safari 4.0+, or other JavaScript-enabled browser
- Cable or DSL Modem (if needed)
- Subscription with an internet service provider (for internet access)
- Certifications: FCC, CE, RoHS
- Environment:
- Operating Temperature: 0℃~40℃ (32℉ ~104℉)
- Storage Temperature: -40℃~70℃ (-40℉ ~158℉)
- Operating Humidity: 10%~90% non-condensing
- Storage Humidity: 5%~90% non-condensing
- TEST DATA
- WiFi Transmission Power CE EIRP: <20dBm(2.4GHz), <23dBm(5GHz)
- FCC: <30dBm(2.4GHz & 5GHz)
- WiFi Reception Sensitivity:
- 5GHz:
- 11a 54M: -73dBm
- 11ac VHT20 MCS8: -68dBm
- 11ac VHT40 MCS9: -64dBm
- 11ac VHT80 MCS9: -60dBm
- 2.4GHz:
- 11g 54M: -76dBm
- 11n HT20 MCS7: -74dBm
- 11n HT40 MCS7: -71dBm
- PHYSICAL
- Dimensions (W×D×H): 9.1 × 5.7 × 1.5 in (229.9 × 144.2 × 36.9 mm)
- Package Content
- Wi-Fi Router Archer C50
- Power Adapter
- RJ45 Ethernet Cable
- Quick Installation Guide
- Warranty: 3-years on part.
